post #31 of 50 Old 05-11-2012, 01:39 PM
Senior Member

SCHNEEDOO's Avatar

Join Date: Jul 2006
Location: Batavia, NY
Posts: 430
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 15
I was using blackout cloth, from Joann's before and the image looks way better on the spandex. I watched half of Avatar the other day and the picture was absolutely stunning. Being able to have the speakers behind the screen also gives my room a more theater like feel. I would recommend the change.
SCHNEEDOO is online now
Sponsored Links
Advertisement

post #32 of 50 Old 05-11-2012, 01:43 PM
Member

rberger3's Avatar

Join Date: Dec 2007
Posts: 73
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by SCHNEEDOO View Post

I was using blackout cloth, from Joann's before and the image looks way better on the spandex. I watched half of Avatar the other day and the picture was absolutely stunning. Being able to have the speakers behind the screen also gives my room a more theater like feel. I would recommend the change.

Do you have a link of where i should get it from and exactly what kind?
rberger3 is offline
post #33 of 50 Old 05-11-2012, 02:02 PM
Senior Member

SCHNEEDOO's Avatar

Join Date: Jul 2006
Location: Batavia, NY
Posts: 430
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 15
This is what I used and I think DevonS also used the same. http://spandexworld.com/c3/catalog/product/6409 Shipping was very quick.
SCHNEEDOO is online now
post #34 of 50 Old 05-14-2012, 02:43 PM - Thread Starter
Advanced Member

DevonS's Avatar

Join Date: Jul 2007
Location: Regina, SK, Canada
Posts: 592
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Yep, that was the stuff. I also used a layer of cheap basic black spandex behind the silver so you can't see thru the screen. I built a frame out of 1x4 boards and before assembly I ran it thru my router table to put two grooves/channels in the back and used window screen spline to secure the spandex to the wood. easy-peasy!

Built on a tight budget: The Cheap Seats Cinema
DevonS is offline
post #35 of 50 Old 06-29-2012, 10:03 AM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
DavidK442,

As you did not mention what PJ your using I had to search out a few of your posts on other Forums.

Try out your Epson 8350 on Living Room mode....or even Dynamic, then calibrate the PJ to the screen's Gray shade.
(...if you haven't already done that....that could be a big reason for your small degree of dissatisfaction...)

Also, and another thing you should try is placing the White spandex directly behind and against the Gray. Even with the tight weave of the Gray, you are leaking substantial lumen out the back, and that results in probably 25% less Foot lambert of reflected brightness.

Those who have had the best success at achieving the best image quality have followed that dictate. And what's really fortunate is that the additional Fabric does not seem to affect the quality of frequency response enough to even matter, seeing that the first layer doesn't seem to affect it at all!

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #36 of 50 Old 07-12-2012, 09:57 PM - Thread Starter
Advanced Member

DevonS's Avatar

Join Date: Jul 2007
Location: Regina, SK, Canada
Posts: 592
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Hey DavidK... I'll have to go over the old thread and see where I left off. I'm terrible at keeping up with documenting the upgrades. Once the upgrades start ramping up I end up enjoying them rather than evaluating and documenting them. rolleyes.gif

Unfortunately, now it's time for an AVR upgrade since my Onkyo 605 stopped giving me video.

I need some calibration on my setup too. I did run thru a calibration disc, but still notice that dark scenes are really crushed. My screen is the silver spandex over black. Colors and bright scenes are amazing, but I'm just not loving horror flicks down there right now. frown.gif

Built on a tight budget: The Cheap Seats Cinema
DevonS is offline
post #37 of 50 Old 07-13-2012, 01:20 AM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
Silver backed with White will take care of that "Crush" , DevonS

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #38 of 50 Old 07-13-2012, 06:41 AM
Member

memphisanid's Avatar

Join Date: Feb 2003
Location: Staunton, VA
Posts: 63
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
DevonS, I have sitting on my floor waiting for me when I get home the silver and white spandex. I will be glad to throw up some pictures on here tonight if you would like me to. I have a completely light controlled basement room so let me know if you would like silver over white and/or the white over the silver for comparison. I am at work at the moment and am unable to look back through the thread but if you need a little artificial light or anything for comparison I have no problem trying my best to take pictures with different lighting.

I would have had it put up last night but I am trying to figure out the screen size I want and how to treat my walls and ceiling. Thumb tacks galore after work to stretch the bad boys out

(I have the Epson Home Cinema 8100)
memphisanid is offline
post #39 of 50 Old 07-13-2012, 06:45 PM
Member

memphisanid's Avatar

Join Date: Feb 2003
Location: Staunton, VA
Posts: 63
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Here are some comparison shots of the silver on top of the white (left half) and White by itself over my wood paneling held up by push pins. Excuse the shift in exposures. (Images 4 and 5 of this set are very indicative of the actual quality )

400

400

400

400

400

It was in a completely light controlled room (except for the light being reflected back from the walls and ceilings. The silver over the white just didnt have the pop that the white on the paneling only had.

Below is the white completely over the silve:

400

400

400

400

Here are some shots from the opening of The Dark Knight with the white over the silver:

400

400

You can see all of the light being reflected in this one. It is about 50% blown out of proportion due to the camera but it is very noticeable.

400

400

Hope this helps. The silver over the white still looked great but in my light controlled room when it was projected onto the white it just felt "right" and thats the way I am leaning towards layering when I frame tomorrow.
memphisanid is offline
post #40 of 50 Old 07-14-2012, 06:30 AM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
I agree with your determination as far as the White over Silver looking better than the reverse in your specific instance. Having a Silver undercoating beneath a White surface was always the best of the DIY paint applications for a controlled to semi-controlled lighting situation produced Black levels that were superior to White alone, and that surely shows up in your images.

The problem back then was that what with most people Rolling on paint (2003-2005) that it was very difficult for people to get just the right amount of paint over the Silver to have it be thin enough to let a decent amount of light pass through to react to the Silver, and then be able to intermingle with the topmost image.

No issues in that regard using a far more porous Spandex.

It is obvious to me however that in fact, although the images on the White alone look "brighter", they are blown out as far as color saturation and a natural look of depth as opposed to the Silver/White combo. Bright isn't all it's cracked up to be, and obviously your White / Silver example shows that to be true as one can see that the darkened returned light beneath the White serves to curtail the overly bright, almost washed out appearance of the White Spandex alone. But there is a distinct difference in image quality in the first Silver over White example shown, where there is ambient light present. The White side is decidedly washed out.

Besides all that, since the Silver Spandex is not in fact a "reflective-oriented" material, the darker color serves to attenuate light a bit. Not much....but enough to be obvious in any direct comparison with a pure White material.

Such is why .....for the most part, we resist the practice of making such obviously weighted comparisons between a White and a Gray, as the end results will always be slanted toward the White surface if sheer brightness is what is being considered as being most desirable.

And it's fur shur that brightness plays a strong part in self-determinations made by many, especially those who are new to the Front PJ genre. It's only when an obvious difference is shown that pre-set ideas and preferences tend to get reversed.

I think that if you had a more proficient PJ with at least 1800-2000+ lumens (...or the 8100 w/new Bulb) that the initial showing by the Silver over White combo would have been much more impressive. One thing that would have, or rather obviously did benefit the 8100's performance with Silver over White was the increased appearance of having deeper contrast. Fir those who have much newer PJs such as the Beamers from Epson / Optoma / Viewsonic and the like, I really do think that your results do not give enough emphasis as to the benefit of having the Silver on top.

But even so, for those with a dedicated and light controlled Theater, and who are especially are looking for a viable alternative to the far more expensive Acoustically Transparent Mfg Screen materials, what you've shown is of almost immeasurable value. The White over Silver does in fact look splendid.

I've taken the liberty of cut & pasting excerpts of the two identical scenes that are both shown with the varying Silver/ white combos.

The bottom image is of course White over Silver


As seen, the depth of shadows, and the richness in color saturation is very apparent in both the Silver over White and the White over Silver combos, but lacking in the "White only" representation. Brightness is the only real advantage the "White only" has over the other two. The White over Silver does show a slight uptick as far as brightness as compared to the Silver over White, but not a whole lot.. Really, it's the presence of enhanced contrast that spells the difference over "White only."

Memphisanid, we all owe you a well deserved thank you for the effort you put out! So now comes the caveat. Using the same chosen scene (...how about the Night shot of the Joker looking through the Armored Truck's windshield...) can you put up a shot of the Silver over White that shows the Silver completely covering the White, the reverse as far as White over Silver, and one each of both alone? and take at least one shot of each in ambient light? If you can do that, such a complete dossier of examples for comparison would be well nigh invaluable to those considering a Spandex solution, and it will most assuredly find it's way into the "Advanced DIY Screens" compilation I'm making for potential "Sticky Status".

No matter what else, ya dun gud. cool.gif

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #41 of 50 Old 07-21-2012, 02:02 PM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
DavidK442,

Good Man!

I'm sure many will welcome that revision as to date I do not recall anyone else ever having reported such surface aberrations using the most popular Silver Moleskin Spandex.

Sooooooo.........where are those Screen shots, Brother? cool.gif









To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #42 of 50 Old 09-03-2012, 01:35 PM
Senior Member

jimmyk36's Avatar

Join Date: Jul 2004
Location: Northern Virginia
Posts: 321
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 7 Post(s)
Liked: 18
Hi all - I also posted elsewhere - I am going to go with silver over white but wanted to know which side of the silver spandex are you projecting on? On side looks shinier than the other.

Thanks,
Jim
jimmyk36 is offline
post #43 of 50 Old 09-03-2012, 02:26 PM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
Quote:
Originally Posted by jimmyk36 View Post

Hi all - I also posted elsewhere - I am going to go with silver over white but wanted to know which side of the silver spandex are you projecting on? On side looks shinier than the other.
Thanks,
Jim

use the non glossy side

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #44 of 50 Old 09-03-2012, 04:42 PM
Senior Member

jimmyk36's Avatar

Join Date: Jul 2004
Location: Northern Virginia
Posts: 321
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 7 Post(s)
Liked: 18
Great - Thanks MM!

I am assuming the underlying white shouldn't matter which side?
jimmyk36 is offline
post #45 of 50 Old 09-05-2012, 06:36 AM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
Quote:
Originally Posted by jimmyk36 View Post

Great - Thanks MM!
I am assuming the underlying white shouldn't matter which side?

Probably not, however it would be best to play it safe and use the flat (matte )side to avoid any chance of glare coming through on very bright content.

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #46 of 50 Old 11-08-2012, 12:15 PM
Senior Member

SCHNEEDOO's Avatar

Join Date: Jul 2006
Location: Batavia, NY
Posts: 430
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 15
I originally used black spandex as the backer for the Silver Moleskin. I had been hearing about the benefits of using white spandex as a backer so I tried it and have been impressed with the results. My projector is a Sony VPL-AW15 paired with a Panasonic DMP-BDT500 player. I did notice a brightness boost and I'm glad I made the switch. This screen shot is silver over white.

SCHNEEDOO is online now
post #47 of 50 Old 11-19-2012, 09:05 PM
Senior Member

Duke Broadway's Avatar

Join Date: Feb 2012
Location: Lincoln, NE
Posts: 267
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
I would be interested in seeing a direct comparo of the black backed moleskin vs the white backed silver moleskin
Duke Broadway is offline
post #48 of 50 Old 11-20-2012, 03:56 AM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
The visual differences between a reflective backing and a absorptive backing are tied to the amount of light that strikes the Screen surface, as well as the reflectivity / absorbancy quotient of the screen surface itself. Light lost and not reclaimed...even in the smaller amounts, means attenuation regardless of the Screen surface used.

Front / Rear

Bright White w/Black :good

Gray w/White :good

White w/Silver :good

Silver w/Black :poor unless dealing with uber-lumen output

While some combinations can be more broadly geared, DavidK442 has it right....one must experiment to find the balance needed for an optimal end result, and much of any satisfaction will be wholly dependent upon the tastes of the viewer. One size does not fit all needs, PJ & room specs, or personal tastes....but some combos do go further than others do.

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
post #49 of 50 Old 11-20-2012, 04:10 AM
Senior Member

Duke Broadway's Avatar

Join Date: Feb 2012
Location: Lincoln, NE
Posts: 267
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Thanks. Just trying to sort out if I am gonna use the silver metallic as the backer or the back side of that which is white with a sheen to it.
Duke Broadway is offline
post #50 of 50 Old 11-20-2012, 04:17 AM
AVS Club Gold

MississippiMan's Avatar

Join Date: Nov 2002
Location: Byhalia, Mississippi. Waaaay down in the Bottoms
Posts: 14,869
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 135 Post(s)
Liked: 216
I'd use the SM as you stated it's matte. Sheen can be risky when the overlaying material is as porous as spandex. One needs a uniform degree of reflectivity, and anything with any real degree of sheen risks transferring a pinpoint reflection of the light source

To quote James T. Kirk;
"I'm laughing at the superior intellect"
MississippiMan is offline
