post #1 of 14 Old 10-24-2012, 08:47 AM - Thread Starter
AVS Special Member

tgm1024's Avatar

Join Date: Dec 2010
Posts: 7,684
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 1186 Post(s)
Liked: 1227
I honestly think we [defined: public at large & manufacturers, not the calibration crew here] have gone nuts with this rampant promotion and obsession with darker than dark black levels.

Why?

Uber dark black levels are not "good" black levels, they're just Uber dark black levels. What I want are black levels that aren't part of a luminance curve that takes everything from dark brown and dark or very dark gray or black and squashes it down to a visual rip in space time. And even if you're lucky enough to get something that moves ONLY recognizably black objects to this super black, it still is overboard IMO.

Hyperbole aside, I look at some of these panels and realize that the black levels they're displaying only appear in nature on the panels themselves.

Using Artificial Life algorithms, I created a bunch of creatures and let them evolve on my system. Over the years they gained intelligence, a society, and quite a few interesting abilities. However, using the rules from their world, they concluded that I did not exist. So I created a special creature meant to spread the Word about Me with amazing magical abilities that only He had. Went well, until they decided to nail the poor Guy to a tree.
tgm1024 is online now
Sponsored Links
Advertisement

post #2 of 14 Old 10-24-2012, 09:33 AM
AVS Special Member

sotti's Avatar

Join Date: Aug 2004
Location: Seattle, WA
Posts: 6,678
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 70 Post(s)
Liked: 195
No uber dark black levels are very important.

They effect contrast ratio, but also significantly affect color reproduction.

Up to even 30% stimulus the amount of light "black" produces significantly pollutes colors desaturating them.

This isn't to say some of the tricks they play to try and get better black levels are good. Much of the dynamic contrast, dynamic backlight features make the TV measure like it has a better black level, but don't actually address the issues created with poor black levels.

Joel Barsotti
SpectraCal
CalMAN Lead Developer
sotti is online now
post #3 of 14 Old 10-24-2012, 12:37 PM
AVS Special Member

buzzard767's Avatar

Join Date: Dec 2005
Location: Naples, FL & Wausau, WI
Posts: 4,275
Mentioned: 11 Post(s)
Tagged: 1 Thread(s)
Quoted: 545 Post(s)
Liked: 1054
MLL is the main determiner of contrast ratio and contrast ratio is the single most import aspect of picture quality as we see it.

Buzz
THX Certified Video Calibrator



buzzard767 is online now
post #4 of 14 Old 10-24-2012, 08:58 PM
Senior Member

turboman123's Avatar

Join Date: Jul 2011
Posts: 357
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 7 Post(s)
Liked: 24
Quote:
Originally Posted by sotti View Post

They effect contrast ratio, but also significantly affect color reproduction.
Up to even 30% stimulus the amount of light "black" produces significantly pollutes colors desaturating them.

hello Sotti,I have problems understanding how black level affects color reproduction. I always thought that color depends on RGB of the greyscale, and the gamut. So how does black level come into play?
Can you pls explain? Thanks.
turboman123 is offline
post #5 of 14 Old 10-25-2012, 08:21 AM
AVS Special Member

sotti's Avatar

Join Date: Aug 2004
Location: Seattle, WA
Posts: 6,678
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 70 Post(s)
Liked: 195
Quote:
Originally Posted by turboman123 View Post

hello Sotti,I have problems understanding how black level affects color reproduction. I always thought that color depends on RGB of the greyscale, and the gamut. So how does black level come into play?
Can you pls explain? Thanks.

So normalize linear levels are 0-1

if red at 10% would be .006, 0 ,0 for a gamma of 2.2

With lets say a modest contrast ratio of 1000:1 instead you have 0.006, 0.0001, 0.0001 for red.

So instead of 0.64, 0.33 you get 0.639, 0.6158, 0.329.

And that's assuming the black level is actually D65, and it never is. The point is that you're mixing some amount of light into your colors that has a measurable effect on the results. Above about 50% it's no longer measurable.

Joel Barsotti
SpectraCal
CalMAN Lead Developer
sotti is online now
post #6 of 14 Old 10-25-2012, 08:38 AM
AVS Special Member

Crabalocker's Avatar

Join Date: Aug 2010
Posts: 1,100
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 134 Post(s)
Liked: 78
I don't know about the measurements and scientific stuff only a real world visual experience. I own the Epson 8350 and the 8500Ub. I thought, after doing quick back and forth comparisons, that the difference between the two were only slight, not that big of a noticeable difference. It wasn't till after watching the 8350 for 6+ straight weeks and then going back to the 8500Ub did I really truly appreciate what deep blacks did for my viewing experience. I couldn't believe how much nicer the picture looked with better blacks. It's kind of like going out in a hazy night and then going out on a clear crisp night with a good bright moon. It's hard to explain but those blacks (for me) made a huge difference.
Crabalocker is offline
post #7 of 14 Old 10-25-2012, 08:48 AM - Thread Starter
AVS Special Member

tgm1024's Avatar

Join Date: Dec 2010
Posts: 7,684
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 1186 Post(s)
Liked: 1227
A step to the side here.

Something I have some fun with is the notion of color constancy. It's a good thing to keep in mind (pun), whenever I read (anywhere, I don't mean specifically *here*) the words "noticeable" or "effective" or "realistic".

What your mind sees as shades are more dependent upon the surroundings than most understand. Ironically, I started banging into this when developing the high speed RGB to YIQ conversion algorithm for a PostScript interpreter in the 80's. The reasons behind color constancy are very interesting and are not eye but brain driven. But if you haven't seen it at work yet, ask yourself: which square is darker, A or B?


Using Artificial Life algorithms, I created a bunch of creatures and let them evolve on my system. Over the years they gained intelligence, a society, and quite a few interesting abilities. However, using the rules from their world, they concluded that I did not exist. So I created a special creature meant to spread the Word about Me with amazing magical abilities that only He had. Went well, until they decided to nail the poor Guy to a tree.
tgm1024 is online now
post #8 of 14 Old 10-25-2012, 10:03 AM
AVS Special Member

GeorgeAB's Avatar

Join Date: Feb 2002
Location: Denver, CO
Posts: 3,406
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 40 Post(s)
Liked: 139
From the "sticky" threads above:

"How Viewing Environment Conditions Can Corrupt Or Enhance Your Calibration"
http://www.avsforum.com/avs-vb/showthread.php?t=849430
GeorgeAB is offline
post #9 of 14 Old 10-25-2012, 10:19 AM
Member

Killerbeenl's Avatar

Join Date: Dec 2007
Location: Netherlands
Posts: 160
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Quote:
Originally Posted by tgm1024 View Post

A step to the side here.

Something I have some fun with is the notion of color constancy. It's a good thing to keep in mind (pun), whenever I read (anywhere, I don't mean specifically *here*) the words "noticeable" or "effective" or "realistic".

What your mind sees as shades are more dependent upon the surroundings than most understand. Ironically, I started banging into this when developing the high speed RGB to YIQ conversion algorithm for a PostScript interpreter in the 80's. The reasons behind color constancy are very interesting and are not eye but brain driven. But if you haven't seen it at work yet, ask yourself: which square is darker, A or B?


They are both at the same grey stimulus wink.gif

Sometimes you are 1 click away from pulling your hair out and bang your head against the wall
Killerbeenl is offline
post #10 of 14 Old 10-25-2012, 10:24 AM - Thread Starter
AVS Special Member

tgm1024's Avatar

Join Date: Dec 2010
Posts: 7,684
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 1186 Post(s)
Liked: 1227
Yep. I posted this not to lecture anyone here, but as OP to show where I was coming from before posting my initial comment.

For fun, and just in case someone perusing this is confused by it, here's the proof I concocted:


Using Artificial Life algorithms, I created a bunch of creatures and let them evolve on my system. Over the years they gained intelligence, a society, and quite a few interesting abilities. However, using the rules from their world, they concluded that I did not exist. So I created a special creature meant to spread the Word about Me with amazing magical abilities that only He had. Went well, until they decided to nail the poor Guy to a tree.
tgm1024 is online now
post #11 of 14 Old 10-25-2012, 10:57 AM
AVS Special Member

Crabalocker's Avatar

Join Date: Aug 2010
Posts: 1,100
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 134 Post(s)
Liked: 78
I love being mind F#@%ED. Still After viewing the 8350 for 6+ weeks and then switching back to the 8500Ub, the effective results on quality as perceived through my mind F#@%ED eyes appeared to be noticeably more realistic on the 8500Ub tongue.gif
Crabalocker is offline
post #12 of 14 Old 10-26-2012, 01:57 AM
AVS Special Member

sotti's Avatar

Join Date: Aug 2004
Location: Seattle, WA
Posts: 6,678
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 70 Post(s)
Liked: 195
Quote:
Originally Posted by Crabalocker View Post

I love being mind F#@%ED. Still After viewing the 8350 for 6+ weeks and then switching back to the 8500Ub, the effective results on quality as perceived through my mind F#@%ED eyes appeared to be noticeably more realistic on the 8500Ub tongue.gif

I just spend last several days at the SMPTE conference, and I can assure you that you are not crazy.

Every industry professional want great blacks (the real kind, not the fake backlight, dynamic contrast kind) because of exactly what you are describing.

Joel Barsotti
SpectraCal
CalMAN Lead Developer
sotti is online now
post #13 of 14 Old 10-26-2012, 09:44 AM
AVS Special Member

PlasmaPZ80U's Avatar

Join Date: Feb 2009
Posts: 7,919
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 446 Post(s)
Liked: 256
I can also add to this thread. I switched my main display from a S-IPS panel LG LCD (42LK450) to a S-PVA panel Samsung LED-LCD (UN46EH6030). The native contrast ratio on the LG was a bit under 1000:1 and the native contrast ratio on the Samsung is just a bit over 3,200:1. As a result, the blacks are much, much darker on the Samsung and it really makes the picture 'pop' in a good way and brings real depth to colors and everything else. Granted a Panasonic ST/GT/VT50 would take things to a whole new level, but I wanted a 46" under $1K and for that, the new Samsung couldn't be any better. I was never happy with the blacks on the LG and calibration didn't really address that issue.

UN46EH6030 Calibration/Settings
Display: Samsung UN46EH6030 LED-LCD TV; Audio: Yamaha HTR-3066 AVR/AMP, Sony Core Bookshelves (Sony SS-CS5) and Center (Sony SS-CS8) as fronts, Cambridge Audio S20 Bookshelves (CA S20-N) as surrounds, Dayton Audio SUB-1200 as subwoofer; Sources: PS4 (doubles as primary BD player), Xbox One, PS3, Xbox 360, Motorola RNG150N (Cable Box)
PlasmaPZ80U is online now
post #14 of 14 Old 10-26-2012, 10:14 AM
AVS Special Member

GeorgeAB's Avatar

Join Date: Feb 2002
Location: Denver, CO
Posts: 3,406
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 40 Post(s)
Liked: 139
An excellent resource available on this issue can be ordered as a digital download from the SMPTE archives:
SMPTE Journal, 11/02. 'The Importance of Contrast and its Effect on Image Quality' by Segler, Pettitt and Kessel
