post #91 of 122 Old 11-18-2009, 12:03 PM
AVS Special Member

Chiahead's Avatar

Join Date: Dec 2005
Location: Parker Colorado
Posts: 1,618
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
Billy search for Power Bridge.

Basically, you have an outlet in another room. The UPS plugs into it, and from the UPS, it goes to a power inlet (prongs sticking out of the wall)

that inlet goes to the outlet by your projector and the projector plugs into it.

don't worry about the prongs being exposed, there is no power in them if you can see them. You have to plug that end into the UPS to get that line powered.

This way your projector is on a UPS circuit, and the UPS device is elswhere so as not to take up room.

Michael

PSN: Chiahead
Chiahead's Man Cave - Indexed
Loganed on 8/29/2008
Chiahead is offline
Sponsored Links
Advertisement

post #92 of 122 Old 11-18-2009, 01:40 PM
Newbie

Billy_P's Avatar

Join Date: Jun 2008
Location: Podunk, ND
Posts: 8
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Thanks Chiahead. I had seen the Power Bridge metioned on AVS forum before, but I'd never really looked into it... I just ordered one! That should solve my UPS issue without needing an electirician.

I'll assume the location is OK. It seems that location of the outlet and conduit isn't a real big deal. Just lets you minimize the cabling that shows, obviously.
Billy_P is offline
post #93 of 122 Old 11-18-2009, 07:50 PM
Senior Member

bhuttman's Avatar

Join Date: Jul 2009
Location: Burlington, ON
Posts: 372
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Location of the projector depends on your screen size, throw distance, brightness capability of the projector (lumens), ambient lighting, and your seating location. My screen will be 100", seating is at 11-12', and the projector at about 14'. Sounds like you've got it figured out, though! Good luck!
bhuttman is offline
post #94 of 122 Old 11-19-2009, 04:45 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Quote:
Originally Posted by Billy_P View Post

Thanks Chiahead. I had seen the Power Bridge metioned on AVS forum before, but I'd never really looked into it... I just ordered one! That should solve my UPS issue without needing an electirician.

I'll assume the location is OK. It seems that location of the outlet and conduit isn't a real big deal. Just lets you minimize the cabling that shows, obviously.

No problem Billy, and I agree with all the suggestions. I do have an outlet on the cieling behing where the screen will be. Ironic thing is I just bought a manual screen as I found a terrific deal. The other thing to consider is some framing to make mounting the screen and projector easier. Rather than hunt for studs, I chose to run some additional blocking in the areas of the ceiling mounts for the projector and screen. Finally, I chose a more local solution for surge protection, an APC wall mount power filter, check out the bargain basement price!

davboy is offline
post #95 of 122 Old 11-24-2009, 06:04 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Here's some updated photos on the pool table area, just stained the floor yesterday:







More mudding and taping today, and hanging some cabinets up.
davboy is offline
post #96 of 122 Old 11-24-2009, 06:07 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Gotta love Amazon. Bought a Onkyo AVR 607 on the 19th from Amazon for what I thought was a decent deal at $400. Saw they had it today for $349 with a free ipod dock. Called them up and they refunded the difference no problem. I passed on the dock though. I have an Apple TV for the basement so I don't see ever using the dock down there. Really appreciated the prompt refund from Amazon though.
davboy is offline
post #97 of 122 Old 11-25-2009, 05:27 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Last night's project, finishing the cabinets in the kids area for storage.



Today's project, hanging cabinets in Bar Area:



Can't wait to start putting some things where they belong, and to have the refrigerators going in the basement!
davboy is offline
post #98 of 122 Old 11-25-2009, 06:38 AM
AVS Special Member

cuzed2's Avatar

Join Date: Nov 2006
Location: Chicago Area
Posts: 4,404
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 63
Dave,

You're really cranking now. Lots of nice cabinets - where did you get them?

The stained floor looks good. Once it is stained: I assume you follow-up with a seal coat?

Cuzed2
Check out a video of my theater here
CuznEddy Cinema
Officially Hanesamatized on 8/1/09

cuzed2 is offline
post #99 of 122 Old 11-25-2009, 07:01 AM
Advanced Member

KNKKNK's Avatar

Join Date: Feb 2009
Location: AZ
Posts: 868
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 27 Post(s)
Liked: 76
Dave, your project is coming together quite nicely.

Curious the concrete stain. Could you give us a quick run down of the process and your overall thoughts.

Much appreciated
Brad

My Basement HT Construction ~ Faster than the speed of Dark

"I've cut that piece 3 times and its still too short..."
KNKKNK is offline
post #100 of 122 Old 11-25-2009, 08:30 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Thanks for the comments on the concrete stain. I've always wanted to have a basement floor acid stained. That is, until I heard a couple horror stories on them turning out radically different than planned, etc. My wife and I had been going back and forth on the floor covering, from wood (scared me to death in the basement) to carpet, to vinyl plank wood look, etc, to ceramic tile, etc. I was in Menards for about the 100th time a couple months ago and noticed Rustoleum had a concrete stain product, and it was on sale. I went home and did some quick research, finding generally positive reviews. I figured for a couple hundred bucks, no harm no foul if I screwed it up, so decided to give it a try.

It turns out it is a really nice product. I went with a two stage application, putting down a layer a Burnt Brick, then a layer of Sienna at about 50% the amount of the burnt brick. I then applied two coats of clear gloss sealer.

The product is applied with a sprayer, making it incredibly easy. It's semi-transparent so it doesn't look like paint at all, which I like, and it is a penetrating stain.

The final clear gloss coat doesn't make it quite as glossy as I would like, but after more research I found that it can be polished to a ultra high gloss, which I'll do once everything is done. So far I am extremely happy with how it has turned out! We do plan on getting a couple big area rugs to break it up. The nice thing is down the road we can always cover it with carpet or something else if we want a change.

Here's the sequence I used. it may vary slightly from the instructed method, but I'm very happy with it:

1. Completely clean, clear, sweep and wet mop the area (wet mopped several times)
2. Apply etching solution (Rustoleum brand) and scrub with a hard bristle broom
3. Wet mop two more times to rinse
4. Let dry completely
5. Apply base color stain (burnt brick) with sprayer, keeping nozzle on a fairly fine mist. Apply in circular motion at about 70-80% coverage
6. Let dry.
7. Apply a second light coat of base color to increase depth.
8. Let dry.
9. Apply accent color (Sienna) at about 50% coverage.
10. Let dry.
11. Apply Clear Gloss Sealer (Rustoleum).
12. Let dry
13. Apply second coat of Clear Gloss Sealer
davboy is offline
post #101 of 122 Old 11-25-2009, 08:40 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Here is a photo of the concrete stain product if anyone is interested:



Also, I have a barely used Drywall lift for sale if anyone in the Chicago area is interested!
davboy is offline
post #102 of 122 Old 11-25-2009, 08:43 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Quote:
Originally Posted by cuzed2 View Post

Dave,

You're really cranking now. Lots of nice cabinets - where did you get them?

The stained floor looks good. Once it is stained: I assume you follow-up with a seal coat?

All the cabinets are from Ikea. We've actually moved some of them around from House to house and have repurposed them. They've held up well. There is some color variation when you have to buy some new ones to supplement, but after a couple months they all seem to even out.
davboy is offline
post #103 of 122 Old 11-25-2009, 09:56 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Today's progress:

7 AM



5 PM



10 PM



Taking a couple days off to visit family near Indianapolis and enjoy the family. My bones need some rest. Getting very close to the end of the tunnel, the OCD has its hold on me!
davboy is offline
post #104 of 122 Old 11-26-2009, 06:03 AM
Advanced Member

KNKKNK's Avatar

Join Date: Feb 2009
Location: AZ
Posts: 868
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 27 Post(s)
Liked: 76
Quote:
Originally Posted by davboy View Post


Here's the sequence I used. it may vary slightly from the instructed method, but I'm very happy with it:

1. Completely clean, clear, sweep and wet mop the area (wet mopped several times)
2. Apply etching solution (Rustoleum brand) and scrub with a hard bristle broom
3. Wet mop two more times to rinse
4. Let dry completely
5. Apply base color stain (burnt brick) with sprayer, keeping nozzle on a fairly fine mist. Apply in circular motion at about 70-80% coverage
6. Let dry.
7. Apply a second light coat of base color to increase depth.
8. Let dry.
9. Apply accent color (Sienna) at about 50% coverage.
10. Let dry.
11. Apply Clear Gloss Sealer (Rustoleum).
12. Let dry
13. Apply second coat of Clear Gloss Sealer

Thanks for the run down. I'm Leaning this way for the bar/gameroom portion of my basement.

Was the acid etch offensive.. ie severe oders, or skin itching just walking in the same room while applying etc..

Brad

My Basement HT Construction ~ Faster than the speed of Dark

"I've cut that piece 3 times and its still too short..."
KNKKNK is offline
post #105 of 122 Old 11-26-2009, 07:42 AM
AVS Special Member

cuzed2's Avatar

Join Date: Nov 2006
Location: Chicago Area
Posts: 4,404
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 63
Dave,

Thanks for the info on the floor!
Enjoy the Holiday - I'll bet you're hard at it again before Sunday slips by

Cuzed2
Check out a video of my theater here
CuznEddy Cinema
Officially Hanesamatized on 8/1/09

cuzed2 is offline
post #106 of 122 Old 11-28-2009, 05:18 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Quote:
Originally Posted by KNKKNK View Post

Thanks for the run down. I'm Leaning this way for the bar/gameroom portion of my basement.

Was the acid etch offensive.. ie severe oders, or skin itching just walking in the same room while applying etc..

Brad

The etching wasn't a problem at all. I believe the Rustoleum product is some type of citric solution, if that makes any difference. Hardly any odor at all.
davboy is offline
post #107 of 122 Old 11-28-2009, 05:19 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Quote:
Originally Posted by cuzed2 View Post

Dave,

Thanks for the info on the floor!
Enjoy the Holiday - I'll bet you're hard at it again before Sunday slips by

Saturday morning, 6 AM! I can see the finish line (at least the finish of the stuff I'm tired of, mudding, taping, painting!)

That's part of why my order is somewhat out of whack. Trying to finish sections of the basement so the family can use it somewhat, and also trying to break up the work. Helps with the WAF at least. It goes between "when are you going to finish" to "why are you spending so much time down there!"
davboy is offline
post #108 of 122 Old 11-28-2009, 05:25 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Having a pool table light dilemma. Had bought a really nice one when we bought all the lights with the house to get the builder's discount. Problem is we forgot about the ping pong top, and with the soffit above the table, the light hangs down too far to play ping pong. I saw a nice retracting pool table light that would work, but was $600. I don't like track lights, and cans won't fit in the soffit due to ductwork. I was thinking a brushed nickel bar with 3 or four LED lights that was basically was flush would be nice, but can't find anything like that. Any thoughts
davboy is offline
post #109 of 122 Old 11-28-2009, 08:32 AM
AVS Special Member

cuzed2's Avatar

Join Date: Nov 2006
Location: Chicago Area
Posts: 4,404
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 63
Quote:
Originally Posted by davboy View Post

Helps with the WAF at least. It goes between "when are you going to finish" to "why are you spending so much time down there!"

Ha, ha !
I wish I had a buck every time I heard "Have fun down in the hole, you know it's already been __ months"

Cuzed2
Check out a video of my theater here
CuznEddy Cinema
Officially Hanesamatized on 8/1/09

cuzed2 is offline
post #110 of 122 Old 11-28-2009, 09:54 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Here's a link to the Drywall lift ad if anyone is interested:

http://chicago.craigslist.org/sox/tls/1485373825.html
davboy is offline
post #111 of 122 Old 12-18-2009, 06:41 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Hoping to Hang projector screen and projector this weekend. Here's some updated photos:



davboy is offline
post #112 of 122 Old 12-18-2009, 08:46 AM
AVS Special Member

cuzed2's Avatar

Join Date: Nov 2006
Location: Chicago Area
Posts: 4,404
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 63
DavBoy,

Damn this is looking good , Very good !!

Need any help cleaning up all of that excess wine

Cuzed2
Check out a video of my theater here
CuznEddy Cinema
Officially Hanesamatized on 8/1/09

cuzed2 is offline
post #113 of 122 Old 12-18-2009, 03:37 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
I do actually! That's why there is so much of it! Just got the projector and screen hung, will post some pictures on Sunday hopefully. It's more functional than technically correct, just a manually operated pull down screen hidden behind a valence to start. I'm actually really happy with the screen though, bargain find on Amazon and it has no waves in it whatsoever.
davboy is offline
post #114 of 122 Old 12-21-2009, 04:21 AM
Advanced Member

KNKKNK's Avatar

Join Date: Feb 2009
Location: AZ
Posts: 868
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 27 Post(s)
Liked: 76
Dave.. Everything looks fantastic, and with 30+ bottles that I can count + whatever's in the cooler you should'nt need to leave the basement for awhile.

Brad

P.S. showed the wife the stained concrete in your thread, she's sold on too so Ill also be going that route in the general bar/game room portion of the basement.. thanks again for the info.

My Basement HT Construction ~ Faster than the speed of Dark

"I've cut that piece 3 times and its still too short..."
KNKKNK is offline
post #115 of 122 Old 12-21-2009, 01:14 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
OK, home theater portion of the basement is functional. While it's not a dedicated space and more of an open plan, we watched the first movie last night (Inglorious Bastards) and really enjoyed it. Here's what I ended up with for equipment:

Audio
Onkyo TX-SR 607 AVR
TSC TC2 Center Channel Speaker
TSC TSB 5.25 Bookshelve Speakers (L&R)
Emotiva ERD 1 Bipole/Dipole Surround Speakers
Klipsch Synergy III Rear Speakers
Yamaha YST SW 315 Subwoofer

Video
Epson Powerlite Home Cinema 720
Panasonic 50 Inch Plasma
Accuscreens 100 Inch Manual Pull Down Screen
Oppo BDP 83
Fat Sony PS 3
Apple TV
Slingbox

Panamax M5100 PM Power Management

None of it is break the bank awesome quality, but it is all certainly adequate, and relatively inexpensive (except when taken in total...yikes!)
davboy is offline
post #116 of 122 Old 12-24-2009, 02:37 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Some photos of screen and projector, as well as wider shots. Forgot to pop flash off so no good screenshots!

Projector:



Screen:



Makeshift Equipment Rack:



Entry:



From Screen:



Kid's Area:

davboy is offline
post #117 of 122 Old 12-29-2009, 07:53 AM
AVS Special Member

Chiahead's Avatar

Join Date: Dec 2005
Location: Parker Colorado
Posts: 1,618
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
What setting did you use for your emotiva surrounds? Dipole or Bipole?

Michael

PSN: Chiahead
Chiahead's Man Cave - Indexed
Loganed on 8/29/2008
Chiahead is offline
post #118 of 122 Old 12-30-2009, 12:21 PM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
I have mine set as Dipole's as they are directly to the side of the listening position. They sound terrific!
davboy is offline
post #119 of 122 Old 01-12-2010, 09:01 AM - Thread Starter
Member

davboy's Avatar

Join Date: Sep 2008
Location: Mokena, IL
Posts: 166
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Getting quotes on the bathroom.
davboy is offline
post #120 of 122 Old 01-12-2010, 09:14 AM
AVS Special Member

Chiahead's Avatar

Join Date: Dec 2005
Location: Parker Colorado
Posts: 1,618
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
Quote:
Originally Posted by davboy View Post

Getting quotes on the bathroom.

I have a quote for your bathroom...

"Here I sit broken hearted, came to poop but mearly farted..."

Or were you looking for a different kind of quote?

Michael

PSN: Chiahead
Chiahead's Man Cave - Indexed
Loganed on 8/29/2008
Chiahead is offline
Reply General Home Theater & Media/Game Rooms

User Tag List

Thread Tools
Show Printable Version Show Printable Version
Email this Page Email this Page


Forum Jump:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off
