post #361 of 822 Old 01-05-2011, 04:58 PM
Member

lsiberian's Avatar

Join Date: Jan 2009
Posts: 40
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by Maxjr View Post

Thanks, Mike! I can always count on you. I'll get dedicated amps for your TH build.

Would you advise to get 3 of the NHT Foster amps or a 300 Bash amp or the Dayton 240? From what I can tell, of the 3 only the NHT has a highpass filter. It would sort of be ideal for me to have just one amp and DSP rather than an amp for each build. However, I'm still a newbie . Are there advantages to having a dedicated amp to each sub?

Any subwoofer plate amp should have a built in high pass filter.
lsiberian is offline
Sponsored Links
Advertisement

post #362 of 822 Old 01-06-2011, 07:02 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Quote:
Originally Posted by lsiberian View Post

Any subwoofer plate amp should have a built in high pass filter.

Good to know. Is there a way of knowing the highpass frequency of each plate amp, and modifying them if needed? Most plate amps I have looked at doesn't spec if there is a highpass and what it's at.
Maxjr is offline
post #363 of 822 Old 01-06-2011, 07:10 PM
AVS Special Member

tsloms's Avatar

Join Date: Dec 2005
Location: Wisconsin
Posts: 1,022
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Liked: 25
Quote:
Originally Posted by Maxjr View Post

Good to know. Is there a way of knowing the highpass frequency of each plate amp, and modifying them if needed? Most plate amps I have looked at doesn't spec if there is a highpass and what it's at.

The Foster amp has a third order 29Hz high pass. Jhidley has full instructions on his website for modifying this filter. Many plate amps do not have high pass filters at all. The only way to know is by reading the specs for them.
tsloms is offline
post #364 of 822 Old 01-06-2011, 07:16 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Quote:


Originally Posted by tsloms
The Foster amp has a third order 29Hz high pass. Jhidley has full instructions on his website for modifying this filter. Many plate amps do not have high pass filters at all. The only way to know is by reading the specs for them.

Thanks, tsloms! This is what I assumed as many specs (Dayton and Oaudio) did not state any high pass filter. It is my understanding that I would have to purchase a separate EQ or DSP if I went this route. Thanks in advance!



What amp do you guys recommend to run two of these 6.5" Exodus Anarchy's off of? Should I purchase 2 of Jack's NHT amps? And, if so, should I get the modified 20Hz highpass version, or buy the standard 29Hz version and modify the Resistors myself? I am pretty proficient in soldering even on small pcb boards if this is the case.
Maxjr is offline
post #365 of 822 Old 01-06-2011, 07:34 PM
AVS Special Member

tsloms's Avatar

Join Date: Dec 2005
Location: Wisconsin
Posts: 1,022
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Liked: 25
One of the Foster amps per sub would be perfect. I would stick with the standard 29hz high pass. The 20hz high pass will be a bit low and put the Anarchy into overexcursion below 25hz at full power. The 29hz high pass will allow use of the full power of the amp.
tsloms is offline
post #366 of 822 Old 01-06-2011, 07:43 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Awesome! Thanks for the quick reply. I really appreciate it
Maxjr is offline
post #367 of 822 Old 01-11-2011, 08:47 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Over the past 2 days, I made some sawdust Here's a pic:



I cut enough birch ply for 2 cabs (1.5 sheets) I used your awesome cutsheets!. I'm waiting for the anarchy's and NHT amps to arrive. A big thanks to lilmike for all of his help and everyone else who made this a reality!
Maxjr is offline
post #368 of 822 Old 01-11-2011, 09:43 PM - Thread Starter
Senior Member

radman12's Avatar

Join Date: Nov 2007
Posts: 221
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 15
be sure to order an extra set of panties too...................
radman12 is offline
post #369 of 822 Old 01-11-2011, 09:50 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Quote:
Originally Posted by radman12 View Post

be sure to order an extra set of panties too...................

Not sure what you mean by this?
Maxjr is offline
post #370 of 822 Old 01-11-2011, 09:58 PM
AVS Special Member

NEO Dan's Avatar

Join Date: Jul 2006
Location: North East Ohio
Posts: 2,978
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
You will

Regards,
Dan
NEO Dan is offline
post #371 of 822 Old 01-11-2011, 10:15 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Is this referring to WAF? Cuz I'm single and of all the tapped horns, this seems to be the smallest and have the highest WAF
Maxjr is offline
post #372 of 822 Old 01-11-2011, 11:14 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
I'm looking to purchase a brad nailer and air compressor for this build and other future projects Do you guys have any recommendations?
Maxjr is offline
post #373 of 822 Old 01-12-2011, 07:56 AM
AVS Special Member

BeerParty's Avatar

Join Date: Jun 2008
Location: New Hampshire, USA
Posts: 1,073
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 17
Quote:
Originally Posted by Maxjr View Post
Is this referring to WAF? Cuz I'm single and of all the tapped horns, this seems to be the smallest and have the highest WAF
No, I think they are referring to the infamous 'brown note'

They may be small, but they can play loud when needed. With two of them you should be able to shake the room.

Chris

"It hurts to admit when you make mistakes - but when they are big enough, the pain only lasts a second."
--Despair, Inc. "Regret"

My AviaTrix TM Build
BeerParty is offline
post #374 of 822 Old 01-12-2011, 09:37 AM
AVS Special Member

lilmike's Avatar

Join Date: Dec 2009
Location: Pacific Northwest
Posts: 2,164
Mentioned: 0 Post(s)
Tagged: 1 Thread(s)
Quoted: 3 Post(s)
Liked: 76
Quote:
Originally Posted by Maxjr View Post

I'm looking to purchase a brad nailer and air compressor for this build and other future projects Do you guys have any recommendations?

I've had good luck with the refurbished Bostitch ones I picked up, as well as my old Craftsman (had that one forever...) and the Hitachi brad nailers I have.

As far as compressors? Are you just gonna shoot nails with it - if so - a little one will work great. If you're going to do anything else (impact wrenches or other air tools) a larger compressor makes sense. I have a little one (part of that Bostitch refurb compressor and nailer kit) that I use as a portable source for shooting nails, hanging trim and stuff, as well as a larger one that I use in the shop.
lilmike is online now
post #375 of 822 Old 01-12-2011, 09:38 AM
AVS Special Member

lilmike's Avatar

Join Date: Dec 2009
Location: Pacific Northwest
Posts: 2,164
Mentioned: 0 Post(s)
Tagged: 1 Thread(s)
Quoted: 3 Post(s)
Liked: 76
Quote:
Originally Posted by Maxjr View Post

Not sure what you mean by this?

Get them done, put them in the corner, and turn them loose.

You'll find out.
lilmike is online now
post #376 of 822 Old 01-12-2011, 12:05 PM
Member

Maxjr's Avatar

Join Date: Dec 2010
Posts: 179
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Quote:
Originally Posted by BeerParty View Post

No, I think they are referring to the infamous 'brown note'

They may be small, but they can play loud when needed. With two of them you should be able to shake the room.

Oh, hahahahah . Now I understand. I'll order a pair of black ones so they don't stain

Quote:
Originally Posted by lilmike View Post

I've had good luck with the refurbished Bostitch ones I picked up, as well as my old Craftsman (had that one forever...) and the Hitachi brad nailers I have.

As far as compressors? Are you just gonna shoot nails with it - if so - a little one will work great. If you're going to do anything else (impact wrenches or other air tools) a larger compressor makes sense. I have a little one (part of that Bostitch refurb compressor and nailer kit) that I use as a portable source for shooting nails, hanging trim and stuff, as well as a larger one that I use in the shop.

I'm probably going to pick up a Hitachi one with what you have said and the reviews on amazon. http://www.amazon.com/Hitachi-NT50AE...4862595&sr=8-1

I will be using this air compressor for possibly impact wrenches in the future. Hopefully I'm not going too off topic here, but how does this air compressor look: http://www.amazon.com/Makita-MAC700-...4862648&sr=1-1

Quote:
Originally Posted by lilmike View Post

Get them done, put them in the corner, and turn them loose.

You'll find out.

A big thanks to lilmike and radman12 for this great thread and outside support. I really appreciate it.
Maxjr is offline
post #377 of 822 Old 01-12-2011, 12:46 PM
Member

dawg1161's Avatar

Join Date: Mar 2006
Location: Anamosa, Iowa
Posts: 161
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Ditto on the above post. This has been a great thread to follow.

Okay , I have the enclosure built. Missed the sale on the Anarchy 6 1/2"...Need to know exactly which 6 1/2" Tang Band to use as a drop in replacement. ? Thanks , can't wait to use this in the bedroom setup.
John.
dawg1161 is offline
post #378 of 822 Old 01-12-2011, 12:46 PM
AVS Special Member

lilmike's Avatar

Join Date: Dec 2009
Location: Pacific Northwest
Posts: 2,164
Mentioned: 0 Post(s)
Tagged: 1 Thread(s)
Quoted: 3 Post(s)
Liked: 76
Tang Band W6-1139SI
lilmike is online now
post #379 of 822 Old 01-12-2011, 12:55 PM
Member

dawg1161's Avatar

Join Date: Mar 2006
Location: Anamosa, Iowa
Posts: 161
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
That has to be the fastest reply i've ever had.
Thank You.

Will order asap.
dawg1161 is offline
post #380 of 822 Old 01-12-2011, 01:30 PM
AVS Special Member

lilmike's Avatar

Join Date: Dec 2009
Location: Pacific Northwest
Posts: 2,164
Mentioned: 0 Post(s)
Tagged: 1 Thread(s)
Quoted: 3 Post(s)
Liked: 76
Quote:
Originally Posted by dawg1161 View Post

That has to be the fastest reply i've ever had.
Thank You.

Will order asap.

I'm here for you guys.....

Seriously - you posted while I was online....
lilmike is online now
post #381 of 822 Old 01-16-2011, 11:52 AM
Member

bassco's Avatar

Join Date: Dec 2010
Posts: 101
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Just plugged up my second one 20 mins ago and had to rush over to here to tell you guys how AWESOME these sound!

I'm using the tang bands and Jack's Foster plate amp along with 1/2" MDF.

Whats so impressive to me about these is how clean the bass sounds....nice, deep, rich bass, not the muddy stuff that I'm used to hearing at my friends places that distracts from music/movies.

This is my first speaker build of any kind. I don't have much experience with good home theatre subwoofers. I have 3 friends who I can compare these to and these easily, no questions asked, have a better, cleaner bass sound.....just like a high quality movie theatre bass, maybe better!

Just want to say thanks to Lilmike and Radman12 for this great design and inspiration! I can't wait to get these veneered up and start on the next 2!

Here's a pic .....still have to PL and screw down the side on this one. I'll have a bunch more pics when they are fully done.

bassco is offline
post #382 of 822 Old 01-17-2011, 12:50 AM - Thread Starter
Senior Member

radman12's Avatar

Join Date: Nov 2007
Posts: 221
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 15
exactly why they are my favorite tapped horn in my household, they are just so clean sounding
radman12 is offline
post #383 of 822 Old 01-17-2011, 01:03 AM
Advanced Member

goku14139268520's Avatar

Join Date: Jun 2008
Location: Wichita, Kansas
Posts: 585
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
Nice picture of the internals there bassco. It just goes to show you what went into designing this sub, no internal waste.
goku14139268520 is offline
post #384 of 822 Old 01-18-2011, 09:56 AM
Member

bassco's Avatar

Join Date: Dec 2010
Posts: 101
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Just for fun, I played this bass test track through the subs and could hear it down to about 23hz

http://www.youtube.com/watch?v=fH_sUK7hJxE
bassco is offline
post #385 of 822 Old 01-23-2011, 07:21 AM
AVS Special Member

Erich H's Avatar

Join Date: Dec 2007
Location: Cincinnati OH
Posts: 5,185
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 160 Post(s)
Liked: 447
Guys I'm going to be meeting with a CNC guy on Tuesday to get these cabinets cut for cheap. They're price is about $70, including all grooves, pilot holes, and dado cuts.

I had a few questions though.

#1. Should I have them cut out an access panel for the driver? I thought it could be on the side and just big enough to get the driver in. Any ideas what size is needed? Or should we not worry about cutting one at all? Seems like a tight squeeze getting the screws in anyway.

#2. Terminals. What should I have them cut out? A small hole for a terminal plate, or should they just drill 2 holes for the tap in style binding posts? And where? Maybe on the access panel?

#3. Should they drill holes for threaded inserts to mount the driver? Does the Anarchy have the same hole spacing as the Tang Band?
Erich H is online now
post #386 of 822 Old 01-23-2011, 09:53 AM
AVS Special Member

jpmst3's Avatar

Join Date: Dec 2005
Location: Davidsville, PA
Posts: 8,115
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked: 186
I wouldn't worry about the mounting holes. Just get the driver cutouts, any self tapping screw will take care of that.

jpmst3 is offline
post #387 of 822 Old 01-23-2011, 11:27 AM
AVS Special Member

CZ Eddie's Avatar

Join Date: Nov 2000
Location: Austin TX, USA
Posts: 7,061
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 7 Post(s)
Liked: 12
I won't be buying any flat packs, since I have all my own tools for cutting wood (except CNC). But I'll toss my opinions out.

Quote:
Originally Posted by Erich H View Post

#1. Should I have them cut out an access panel for the driver?

As long as the access panel board is swappable for the left or right side of the sub enclosure, then absolutely yes.

Quote:
Originally Posted by Erich H View Post

#2. Terminals. What should I have them cut out?

No. Most people at least have a drill on hand.

Quote:
Originally Posted by Erich H View Post

#3. Should they drill holes for threaded inserts to mount the driver?

No

"The boom is dead, long live the bass"
CZ Eddie is offline
post #388 of 822 Old 01-23-2011, 11:29 AM
AVS Special Member

jpmst3's Avatar

Join Date: Dec 2005
Location: Davidsville, PA
Posts: 8,115
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked: 186
Quote:
Originally Posted by CZ Eddie View Post

I won't be buying any flat packs, since I have all my own tools for cutting wood (except CNC). But I'll toss my opinions out.

As long as the access panel board is swappable for the left or right side of the sub enclosure, then absolutely yes.

No. Most people at least have a drill on hand.

No

Agreed!

No need to add complexity to the process. Keep it simple.

jpmst3 is offline
post #389 of 822 Old 01-23-2011, 11:38 AM
AVS Special Member

Erich H's Avatar

Join Date: Dec 2007
Location: Cincinnati OH
Posts: 5,185
Mentioned: 1 Post(s)
Tagged: 1 Thread(s)
Quoted: 160 Post(s)
Liked: 447
I just figured if they'd cut the terminal holes for free, why not.

I'm not sure there's enough room on the side for an access panel, it might need to go directly behind the driver. But if the hole's too wide, the surrounding 1/2" birch might be a bit fragile.
Erich H is online now
post #390 of 822 Old 01-23-2011, 11:40 AM
AVS Special Member

jpmst3's Avatar

Join Date: Dec 2005
Location: Davidsville, PA
Posts: 8,115
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked: 186
True, but as soon as you do you will have someone that wants it setup differently or ???

jpmst3 is offline
Reply DIY Speakers and Subs

User Tag List

Thread Tools
Show Printable Version Show Printable Version
Email this Page Email this Page


Forum Jump:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off
