[quote=BIGmouthinDC;21352311]

Building the Riser

The Erskine design of the riser involves a perimeter of 2x10s, cross members of 8x10's. The 8x10 space is insulated and an air gap is left at the bottom. a corner slot vent is cut turning the riser into an absorber. The technical details and determining the volume and tuning appropriate for your room are His intellectual property and you should engage him for help if you are interested.




"...an air gap is left at the bottom (of the riser)...."
How do you prevent the insulation from slipping down over time?
DIYHomeTheater is offline
Sponsored Links
Advertisement

post #182 of 369 Old 03-03-2012, 01:08 PM
AVS Club Gold

SierraMikeBravo's Avatar

Join Date: Mar 2007
Location: Topeka, KS
Posts: 1,600
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 88 Post(s)
Liked: 65
Good question! I'll answer it with a cryptic response...per usual. Is the insulation causing the resonances or the cavity formed from the joists that are causing it? I guess the real question is, does it matter if the insualtion is touching the floor or not?

Shawn Byrne
Erskine Group
CEDIA Certified Professional EST II - HAA Level III Certified -THX Certified Professional

Design-Video & Audio Calibration Information

The original Pro Theater Layout
SierraMikeBravo is online now
post #183 of 369 Old 03-04-2012, 06:16 AM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
DIY, In this case the insulation flange was stapled to the joists.
Shawn, just following the plans from your company.
BIGmouthinDC is online now
post #184 of 369 Old 03-04-2012, 11:53 AM
AVS Club Gold

SierraMikeBravo's Avatar

Join Date: Mar 2007
Location: Topeka, KS
Posts: 1,600
Mentioned: 5 Post(s)
Tagged: 0 Thread(s)
Quoted: 88 Post(s)
Liked: 65
Quote:
Originally Posted by BIGmouthinDC View Post

DIY, In this case the insulation flange was stapled to the joists.
Shawn, just following the plans from your company.


Shawn Byrne
Erskine Group
CEDIA Certified Professional EST II - HAA Level III Certified -THX Certified Professional

Design-Video & Audio Calibration Information

The original Pro Theater Layout
SierraMikeBravo is online now
post #185 of 369 Old 03-04-2012, 08:59 PM
Senior Member

DIYHomeTheater's Avatar

Join Date: Mar 2010
Location: Northern Virginia
Posts: 338
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by BIGmouthinDC View Post

DIY, In this case the insulation flange was stapled to the joists.
Shawn, just following the plans from your company.

My longest 2x10 span is 129" on a 2x12 perimeter. Should I use joist hangers?
DIYHomeTheater is offline
post #186 of 369 Old 03-04-2012, 09:15 PM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
IMHO not unless you are planning on having 20 people dancing on the riser. I didn't use them.
BIGmouthinDC is online now
post #187 of 369 Old 03-05-2012, 04:35 AM
Senior Member

DIYHomeTheater's Avatar

Join Date: Mar 2010
Location: Northern Virginia
Posts: 338
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by BIGmouthinDC View Post

IMHO not unless you are planning on having 20 people dancing on the riser. I didn't use them.

Did you secure the riser to the floor?

I wont be able to get the framing nails into the 2x10 (decking) studs from outside the perimeter framing on the back wall (the way I would have liked). My option then is to toe-nail them in, but never having done this before, not sure if they will hold the weight.
DIYHomeTheater is offline
post #188 of 369 Old 03-05-2012, 04:46 AM
Senior Member

DIYHomeTheater's Avatar

Join Date: Mar 2010
Location: Northern Virginia
Posts: 338
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
What's the purpose of putting Green Glue between the layers of decking in the riser and stage? Roofing felt?
DIYHomeTheater is offline
post #189 of 369 Old 03-05-2012, 07:10 AM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
I've built risers/stages with double layers with roofing felt, and Per DE's instructions done triple layers with GG. After thumping around with my size twelve dance shoes I actually prefer the later and that will be the way I would do my next personal theater. It was more rigid and quieter.
BIGmouthinDC is online now
post #190 of 369 Old 03-05-2012, 12:56 PM
AVS Special Member

hanesian's Avatar

Join Date: Nov 2008
Location: Twin Citiesville, MN
Posts: 2,797
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Liked: 39
Quote:
Originally Posted by BIGmouthinDC View Post

for now it is on to the next theater.




Hi Ho Silver ... AWAY!!



bzbase's wife: "Who was that masked man? I wanted to thank him!"

The Un-Theater Un-Build
_________________________________
State Certified Alcohol Disposal Expert.



hanesian is offline
post #191 of 369 Old 03-06-2012, 04:02 AM
AVS Special Member

TMcG's Avatar

Join Date: Mar 2010
Location: Earth
Posts: 2,747
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 297 Post(s)
Liked: 315
Quote:
Originally Posted by BIGmouthinDC View Post

I've built risers/stages with double layers with roofing felt, and Per DE's instructions done triple layers with GG. After thumping around with my size twelve dance shoes I actually prefer the later and that will be the way I would do my next personal theater. It was more rigid and quieter.

Big - I wanted to ask you about this construction method. I have seen Dennis' proscenium plans where two layers of 3/4" sandwich a layer of 1/2" with Green Glue in-between. This makes sense to me for trying to prevent sound vibration from transmitting into the floor and creating flanking noises in other rooms.

But for the riser, I don't really see how green glue and/or felt would come into play. Isn't it best just to glue (construction adhesive) and screw two layers of 3/4" ply with nothing in between for the strongest connection? What exactly does the felt do? Or what is the benefit of using Green Glue in the riser? Thanks in advance for the input!
TMcG is offline
post #192 of 369 Old 03-06-2012, 05:17 AM
AVS Special Member

Tedd's Avatar

Join Date: May 2001
Location: Ontario
Posts: 4,121
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 103 Post(s)
Liked: 74
The roofing felt is inexpensive, and it prevents wood to wood squeaks.
Tedd is online now
post #193 of 369 Old 03-06-2012, 09:19 AM
Senior Member

DIYHomeTheater's Avatar

Join Date: Mar 2010
Location: Northern Virginia
Posts: 338
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by BIGmouthinDC View Post

As promised I am going to recap this project and show some of the intermediate details of the build.

There is going to be bar seating at the back of the riser so some wiring and a conduit were required



Fotto stopped in for a day and lent a hand insulating, connecting the wiring and putting on the decking. A big THANK YOU.

What kind of cabling did you put in? Anything specific for controlling the Components via a wire (CAT5)?
DIYHomeTheater is offline
post #194 of 369 Old 03-06-2012, 10:35 AM

cybrsage's Avatar

Join Date: May 2007
Location: Harrisburg, PA
Posts: 8,074
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 150
I like the look of the stage!
cybrsage is offline
post #195 of 369 Old 03-06-2012, 06:31 PM
Senior Member

DIYHomeTheater's Avatar

Join Date: Mar 2010
Location: Northern Virginia
Posts: 338
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by BIGmouthinDC View Post




What type of electrical boxes are these? I could not find them at the local HD (or maybe I was looking at the wrong kind). Do you have the SKU #?
DIYHomeTheater is offline
post #196 of 369 Old 03-06-2012, 07:36 PM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
Quote:
Originally Posted by DIYHomeTheater View Post

What type of electrical boxes are these? I could not find them at the local HD (or maybe I was looking at the wrong kind). Do you have the SKU #?

http://www.lowes.com/ProductDisplay?...llow&cId=PDIO1

They are at HD too. You need to cut off the metal parts that get in the way. Tin snips.
BIGmouthinDC is online now
post #197 of 369 Old 03-07-2012, 05:02 AM
Senior Member

DIYHomeTheater's Avatar

Join Date: Mar 2010
Location: Northern Virginia
Posts: 338
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Quote:
Originally Posted by BIGmouthinDC View Post

http://www.lowes.com/ProductDisplay?...llow&cId=PDIO1

They are at HD too. You need to cut off the metal parts that get in the way. Tin ships.

I think that I will get the standard size from HD (21 cu. in.) and not the refrigerator sized version from Lowes (21 cu. ft.)

Thanks
DIYHomeTheater is offline
post #198 of 369 Old 03-07-2012, 09:58 AM
Advanced Member

GWCR's Avatar

Join Date: Jul 2009
Location: Cedar Rapids, IA
Posts: 790
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Liked: 33
Quote:
Originally Posted by DIYHomeTheater View Post

I think that I will get the standard size from HD (21 cu. in.) and not the refrigerator sized version from Lowes (21 cu. ft.)

Thanks

Those look pretty handy. if you need to move your fridge, just turn a screw.
GWCR is offline
post #199 of 369 Old 03-07-2012, 11:11 AM
AVS Special Member

NickTheGreat's Avatar

Join Date: Jan 2012
Location: Des Moines, Iowa
Posts: 1,811
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 125 Post(s)
Liked: 98
Ha ha ha. Lowes FAIL
NickTheGreat is offline
post #200 of 369 Old 03-09-2012, 07:14 AM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
The adventure PART II starts now - I'm packed and ready to go. Ready for a day of junk food pit stops.
BIGmouthinDC is online now
post #201 of 369 Old 03-09-2012, 08:04 AM
AVS Special Member

Brad Horstkotte's Avatar

Join Date: Dec 2005
Location: Torrance, CA
Posts: 5,123
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Liked: 57
Pics please - possible third career on Diners, Drive-Ins and Dives?
Brad Horstkotte is offline
post #202 of 369 Old 03-09-2012, 08:44 AM
AVS Special Member

aaustin's Avatar

Join Date: Dec 2010
Location: Upstate NY
Posts: 1,226
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 32
Quote:
Originally Posted by BIGmouthinDC View Post

The adventure PART II starts now - I'm packed and ready to go. Ready for a day of junk food pit stops.

Oh now I'm excited! Are there any time constraints this time?

The Austin Home Theater:
A DIY high school project (now complete and being enjoyed everyday)

aaustin is offline
post #203 of 369 Old 03-09-2012, 11:03 AM
AVS Special Member

smakovits's Avatar

Join Date: May 2007
Posts: 2,080
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
Whats the ETA in Ohio?
smakovits is offline
post #204 of 369 Old 03-09-2012, 11:41 AM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
Dinner time, I'm at the Somerset PA, service plaza. I stopped at the outlet mall in Hagerstown and picked up a refurbished Rigid job site radio for $80 at Tools Direct, normally $149. Now I'm on the hunt for frozen yogurt. may have to settle for an ice cream bar.
BIGmouthinDC is online now
post #205 of 369 Old 03-09-2012, 11:56 AM
AVS Special Member

damelon's Avatar

Join Date: Sep 2007
Location: Woodbridge, VA
Posts: 1,730
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Liked: 114
Here we go again! Went to a football game once at Akron vs VaTech. Isn't the stadium called "The Rubber Bowl"?
damelon is offline
post #206 of 369 Old 03-09-2012, 12:26 PM
Senior Member

randy98mtu's Avatar

Join Date: Jul 2002
Location: Michigan
Posts: 372
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
Hearing about BIG's road trips makes me want to see if he is interested in driving a couple more hours to the other side of Detroit.

Have fun guys!
randy98mtu is offline
post #207 of 369 Old 03-09-2012, 12:56 PM
AVS Special Member

fotto's Avatar

Join Date: Nov 2003
Location: N.E. OH
Posts: 1,869
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Liked: 19
Quote:
Originally Posted by damelon View Post

Here we go again! Went to a football game once at Akron vs VaTech. Isn't the stadium called "The Rubber Bowl"?

Yep, The Rubber Bowl, although U of A has a brand new stadium they play at now (on campus). Not much going on at the old Bowl, except for the Soap Box Derby (which is right next to it).
fotto is offline
post #208 of 369 Old 03-09-2012, 01:19 PM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
Warrinton pa, clean rest room at McD. At least it was.
BIGmouthinDC is online now
post #209 of 369 Old 03-09-2012, 01:25 PM
AVS Special Member

aaustin's Avatar

Join Date: Dec 2010
Location: Upstate NY
Posts: 1,226
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 32
Quote:
Originally Posted by BIGmouthinDC View Post

Warrinton pa, clean rest room at McD. At least it was.

Hahahahahahaha!

The Austin Home Theater:
A DIY high school project (now complete and being enjoyed everyday)

aaustin is offline
post #210 of 369 Old 03-09-2012, 02:17 PM - Thread Starter
HOME THEATER CONTRACTOR

BIGmouthinDC's Avatar

Join Date: Jan 2003
Location: Northern VA
Posts: 21,373
Mentioned: 10 Post(s)
Tagged: 1 Thread(s)
Quoted: 525 Post(s)
Liked: 722
I'm in Ohio, grabbed some gas and bold coffee, almost something else, more on that later, north Lima, easy off easy on.
BIGmouthinDC is online now
Reply Dedicated Theater Design & Construction



Forum Jump:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off
