Rabbit Ear and Loop Style AntennasBasic Non-Amplified Rabbit Ears & Loop
Believe it or not, these are pretty darn good antennas. The Rabbit Ears give you good VHF performance, and the basic loop gives you good UHF. These outperform many fancy looking and more expensive Amplified RE & Loops. If you have a pair of these around, you should pull them out and give them a try. They may be all that you need. Indeed they may be the best solution.
Note that those close to the towers can overload their tuners with already strong signals that are then amplified. This wont hurt your tuner/TV(but you shouldnt keep abusing it), but they just wont work.
Some of the best currently available basic RE & Loops from mine and others experience and testing are the RCA ANT110 and the RCA ANT108. These are virtual clones and Ive seen these same units with other brand names on them as well. These are easy to find at major B&M retailers nationwide. The RCA ANT108 is pictured.
They have strong thick 5" loops and 39" telescoping rabbit ear dipoles that are sturdy and simple to adjust. On the downside, they have thinly shielded coax that is not detachable. However, they do perform and are dirt cheap.Radio Shack 15-1868 Delta
The RS Delta has pleasing aesthetics and good user reviews. Plus fine tuning adjustment knob. Good performer for non amplified RE & Loops. This unit has detachable coax and telescoping rabbit ear dipoles that are adjustable in altitude and azimuth. If you dont like the utilitarian looks of the basic models above, this one works well also. Nice little antenna. VHF and UHF.
Terk TV-1 Rabbit Ears
Delta design for a high-tech look.
Use the UHF/VHF/FM indoor antenna with 12-position fine-tuning control to dial in the clearest picture for each station. The unique delta design of this set-top antenna makes it an attractive addition to your viewing room. It has gold plating and 75-ohm VHF/UHF output. The internal loop UHF loop is 39" with black chrome and VHF dipoles. This antenna comes with a 6-ft 75-ohm coaxial cable with gold-plated connectors.
12-position fine-tuning control--no need to move base for best picture
Gold-plated "F" connector output for better signal and picture
Unique delta design makes it an attractive addition to your TV room
Here is Terk's version of the non-amplified basic Rabbit Ears. It has good build quality and nice modern aesthetics, plus 44" VHF dipoles. It comes with a sepereate UHF loop which is not attachable as an integrated UHF/VHF antenna solution. Its made to attach to the back of an old TV and thusly isnt very useful. But it can be used in conjunction with a superior UHF only antenna as many are in this list. If you need to add a VHF Hi antenna after the Feb09 cutoff of analog signals, this is a good choice. In order to join 2 seperate UHF and VHF antennas, you need a VHF/UHF Combiner. Its worth the effort to use a Combiner and not just a basic Splitter for less signal loss and better signal filtering and handling. Channel Master and Winegard offer combiners but you can get the cheapies and they are still better than the basic splitter.
VHF: channels 2-13; UHF: channels 14-69
heavy-gauge 40" retractable VHF dipoles with safety tips
UHF loop antenna
300-ohm to 75-ohm matching transformer
height of base: 3-3/8"; height with dipoles: 12-1/2" - 42-1/2"D
An AVSforum member explains this setup.
Channel Master 4000 Rabbit Ears
Originally Posted by golinux
...... I am in a heavily wooded area (and in a hollow to boot) about 26 miles from the towers. My location has been described as a "worst case scenario".
I have been using a DB2 with a 22db amp in an indoor window for several years. Since there is a VHF station, I have rabbit ears and the DB2 hooked to a signal combiner before going to the amp. This setup picks up all the local stations in analog and also with the Zenith DTT900 converter box. On two of the weaker stations there is some minor dropout if the winds are heavy but nothing I can't live with.
Set top antenna
• 300 Ohm twin lead output
• Dual 40 in., 5-section retractable chrome dipoles with 90° tilt for fine tune adjustments
One of the best of the ubiquitous Amplified Rabbit Ears and Loop style set top antennas, which arent the best performers in general as distance antennas, but may suit your needs best. It doesnt have a loop per se, but a "UHF flat panel array." It is also amplified, 50db overkill(I'm skeptical of that figure), but adjustable and has nice 44" dipoles for VHF reception. Strangely it includes a 75ohm to 300ohm transformer/balun along with a nice guide booklet. Has a detachable coax interface, plus an Aux input with a switch so that you can choose between the antenna or another source. Doesnt have an FM trap, so can be used as an FM antenna as well. One thing to note, is that this is a directional antenna, loops are omni-directional or more precisely bi-directional....and is adjustable in altitude and azimuth. The build quality is good on these, the base is weighty and stable and it sits off of the surface. VHF and UHF.
If you are close to the towers, this highly amplified version may not be for you, although the amp is adjustable like most other amped RE & Loop combo antennas, you may want to try an unamplified version first. Overamplifying strong signals can overload the tuner and you might recieve no stations at all. Overloading will not damage the tuner though, it just wont work. When reading user reviews, often the ultra low scores are by people that get no signals because of this amplifier gain overloading business, unbeknownst to them.
In depth comparative reviews of this and other antennas can be found on the Big River MANT510 page.
50 dB amplification boosts weak signals, expanding your reception range and allowing you to receive more signals over a greater distance.
The highly efficient UHF flat panel array offers improved reception over conventional loop antennas. Due to the flat design, the antenna concentrates the signal for better reception.
44" dipoles adjust 360° with a 180° tilt to deliver the best possible reception.
Together with the adjustable amplification, low noise amplification ensures you of a great reception range and improves and maintains the quality of your signal.
Easy touch control with LED signal increases or decreases amplification strength. Also confirms amplification strength at a glance.
The weighted base stabilizes the antenna's position so you enjoy more positioning choices.
A/B switch - Built-in selector switch makes it easy to change between viewing sources.
Simple sleek, elegant design lines compliment today's new TVs.http://www.consumer.philips.com/cons...nna+SDV2510-27
Terk TV-3 Amplified Rabbit Ears and Loop[/b]Petra SuperPower 32db (Cornet 645A, others)
I really like these antennas. They are excellent performers and are the best of the amplified Rabbit Ears & Loop style antennas. They can be found at major online retailers for dirt cheap as well. The large 9" loop (which is also particularly thick) is the key. It shifts the meat of the gain curve down into the newly re-allocated UHF TV spectrum of Ch. 14 to 51....for superior performance over all others with smaller loops. The amplifier helps as well, if you need the extra umph. Also has Rabbit Ear VHF dipoles for adequate VHF reception. Amplified....UHF and VHF.Radio Shack 15-1874 Budget RE&Loop
This is my new favorite unamplified RE&Loop. Its main claim to fame is that it has a larger 7.5" diameter loop which pushes the gain curve down into the heart of the newly squashed UHF Digital TV spectrum (really it could be even larger like the 9" loop on the Petra SuperPower above that is a very good performer). The RCA ANT108 and others like it have a 6.5" diameter loop. UHF and VHF. Highly Recommended.Quantum FX ANT-102 Indoor
The Quantum FX ANT-102 performs on par with the legendary RS-1880. As you can see they are similarly sized and designed with amplified double loops plus telescoping articulating Rabbit Ear VHF dipoles. The Q FX ANT-102 includes a remotely controlled light duty rotor that works well....can be useful for people with multiple direction transmissions....however even if you dont need this feature, this antenna is one of the elite indoor antennas in current distributino (along with the Silver Sensor, and Terk HDTVa, RS 1892 UFO). Snap one of these up, youll be glad you did. Recommended. UHF and VHF.Lava A-463
The Lava A-463 is also a good antenna similar to the lengendary RS 1880, with amplified double loops and telescoping articulating Rabbit Ear VHF dipoles. However it is smaller, as can be seen in the pic. The Lava A-463 is nearly as good as the RS 1880, beating everthing else in this category except the Q FX ANT-102. I think the Lava gives up something on the lower channels of the UHF band due to its diminuative size to both the ANT-102 and the RS 1880. However, this is not a bad antenna, and is better than any Amplified RE&Single Loop style antenna which is so common. Its just the Q FX ANT-102 is slightly more desirable. UHF and VHF.Philips SDV2750
