Also to get into this
1 hold menu for 8 secs
2 press ESC 2x
3 press right then left
You will then have a window pop up
And then repeat the steps above again
I am referencing this post:
BTW My other bits under DIP-SW6 were at follows:
Bit 0: "0"
Bit 1: "1"
Bit 2: "0"
Bit 3: "1"
Bit 4: "0"
Bit 5: "0" --> set to "1'
Bit 6: "0"
Bit 7: "0"
Absolutely the same thing:
[url=http://iceimg.com/BQ7mWukE/dsc00483][img]http://iceimg.com/BQ7mWukE/dsc00483-thumb.jpg[/img][/url] [url=http://iceimg.com/8NA5h6Zv/dsc00485][img]http://iceimg.com/8NA5h6Zv/dsc00485-thumb.jpg[/img][/url] [url=http://iceimg.com/CNhlV5F3/dsc00487][img]http://iceimg.com/CNhlV5F3/dsc00487-thumb.jpg[/img][/url] [url=http://iceimg.com/c-ruXGv9/dsc00488][img]http://iceimg.com/c-ruXGv9/dsc00488-thumb.jpg[/img][/url] [url=http://iceimg.com/bszf107s/dsc00489][img]http://iceimg.com/bszf107s/dsc00489-thumb.jpg[/img][/url] [url=http://iceimg.com/6Jb0ziU9/dsc00490][img]http://iceimg.com/6Jb0ziU9/dsc00490-thumb.jpg[/img][/url] [url=http://iceimg.com/SS3URQFh/dsc00491][img]http://iceimg.com/SS3URQFh/dsc00491-thumb.jpg[/img][/url]
Last screen - Bit5 switched on.
I've tried different languages: rus, eng, ger.. Just in case. No "LCD Align." or anything like this.
If anyone will find out something more, let us know plz!
Here's the bad news. I have a buddy with the Epson 8500 that has the Extended menu that allows you to converge colors at different points on the screen. You can look up the users manual if you want to see how it works. I had him get into the hidden menu and check his dip switch settings. They are exactly the same settings as the 8350 you have posted above as well as the 8100, the model I have.
So my only conclusion is that the dip switch settings in this hidden menu are not the way to expose the Extended menu. Also, the fact that Epson sends used replacement projectors to people and don't bother to check and calibrate the convergence leads me to believe that there might not be a way to do it, or they're really lazy.
If anyone finds a way to converge the colors, please post it here.
On a positive note, playing with the advanced sharpness settings did help a lot to hide the misalignment. Just a few clicks to the left helped mine.
|Epson Powerlite Home Cinema 8350|
