post #451 of 705 Old 05-22-2011, 01:56 AM
Senior Member

forin's Avatar

Join Date: Jul 2006
Posts: 213
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 12
My Infocomm pass arrived today! Plane tickets and Hotel are all set, should be a nice 30th birthday gift to myself I cannot wait to hear the Danley stuff and to talk to a few of them in person. Then when I arrive home I get to pack all my stuff up and move to a new place. This time a spare bedroom will be the HT room. I am excited to hear the difference between a sealed room and the wide open living rooms I have been using. And then after placing everythning in the room I will see if I can squeeze 2 more dts-10s

Forin
forin is offline
Sponsored Links
Advertisement

post #452 of 705 Old 05-22-2011, 09:54 AM
AVS Special Member

Ivan Beaver's Avatar

Join Date: Dec 2005
Posts: 1,639
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 44
Quote:
Originally Posted by forin View Post

My Infocomm pass arrived today! Plane tickets and Hotel are all set, should be a nice 30th birthday gift to myself I cannot wait to hear the Danley stuff and to talk to a few of them in person. Then when I arrive home I get to pack all my stuff up and move to a new place. This time a spare bedroom will be the HT room. I am excited to hear the difference between a sealed room and the wide open living rooms I have been using. And then after placing everythning in the room I will see if I can squeeze 2 more dts-10s

Forin

We look forward to seeing you. If we can pull it off-we will have some "interesting" things in the demo room. I will mostly be on the show floor booth.

Be sure and spend some time looking at the video offerings (by others). The video side of the show can be quite stunning.

Bring some comfortable walking shoes-you will be doing a lot of that.

Danley Sound Labs

Physics-not fads
Ivan Beaver is offline
post #453 of 705 Old 05-22-2011, 03:38 PM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Iam trying to figure out my coverage needs:

Room is 12.5 Wide 8 High 21 Long (Valuted ceilings) knee wall is 49" tall

Listening position can vary 10-18 feet from plasma.

Iam looking at SH50's (stereo pair, for now), would they be too narrow of coverage in my room, center would come later.
bodhisafa is offline
post #454 of 705 Old 05-22-2011, 03:41 PM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Dont mind the love seat on the side (sorry for the blurry pic)

bodhisafa is offline
post #455 of 705 Old 05-22-2011, 03:43 PM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
bodhisafa is offline
post #456 of 705 Old 05-22-2011, 03:59 PM
AVS Special Member

Ivan Beaver's Avatar

Join Date: Dec 2005
Posts: 1,639
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 44
Quote:
Originally Posted by bodhisafa View Post

Iam trying to figure out my coverage needs:

Room is 12.5 Wide 8 High 21 Long (Valuted ceilings) knee wall is 49" tall

Listening position can vary 10-18 feet from plasma.

Iam looking at SH50's (stereo pair, for now), would they be too narrow of coverage in my room, center would come later.

If you place them against the side walls (they will be angled in), you would gain a couple of things.

The width of the "soundfield" would appear to be wider than it physically is.

YOu would have less reflections off of the side walls.

You would also pick up a little more bass from the left/right mains.

If you want a little bit wider-you could go with the SH60. Same sound-just a wider coverage pattern.

I would like to see them a bit higher than your ceiling allows-so a bit of playing in that area may be needed.

Danley Sound Labs

Physics-not fads
Ivan Beaver is offline
post #457 of 705 Old 05-22-2011, 04:06 PM
AVS Special Member

Ivan Beaver's Avatar

Join Date: Dec 2005
Posts: 1,639
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 44
Quote:
Originally Posted by bodhisafa View Post

Iam trying to figure out my coverage needs:

Room is 12.5 Wide 8 High 21 Long (Valuted ceilings) knee wall is 49" tall

Listening position can vary 10-18 feet from plasma.

Iam looking at SH50's (stereo pair, for now), would they be too narrow of coverage in my room, center would come later.

If you place them against the side walls (they will be angled in), you would gain a couple of things.

The width of the "soundfield" would appear to be wider than it physically is.

YOu would have less reflections off of the side walls.

You would also pick up a little more bass from the left/right mains.

If you want a little bit wider-you could go with the SH60. Same sound-just a wider coverage pattern.

I would like to see them a bit higher than your ceiling allows-so a bit of playing in that area may be needed.

Danley Sound Labs

Physics-not fads
Ivan Beaver is offline
post #458 of 705 Old 05-22-2011, 04:23 PM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Ivan,

So you are saying the SH 50 would not be appropriate for this room. Its only temporary (the room) eventually I will move to a new space.
bodhisafa is offline
post #459 of 705 Old 05-22-2011, 04:26 PM
Advanced Member

vraxoin's Avatar

Join Date: Jan 2002
Location: SF Bay Area
Posts: 719
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 23
Quote:
Originally Posted by bodhisafa View Post

Iam trying to figure out my coverage needs:

Room is 12.5 Wide 8 High 21 Long (Valuted ceilings) knee wall is 49" tall

Listening position can vary 10-18 feet from plasma.

Iam looking at SH50's (stereo pair, for now), would they be too narrow of coverage in my room, center would come later.

Just curious if the plasma is going to be the long-term display or if an AT screen and projector are in the future? The reason I ask is that if you later need to mount a center above that window, because the plasma is in the way, the much lighter SM-60F might be a lot easier to deal with and would still make a fine LCR system.

EDIT: Sorry didn't see the above comment in time, so this may not be an issue at all.
vraxoin is offline
post #460 of 705 Old 05-22-2011, 04:32 PM
Advanced Member

vraxoin's Avatar

Join Date: Jan 2002
Location: SF Bay Area
Posts: 719
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 23
Quote:
Originally Posted by bodhisafa View Post

Ivan,

So you are saying the SH 50 would not be appropriate for this room. Its only temporary (the room) eventually I will move to a new space.

Get a protractor, starting in the corner and using your left or right wall as 0deg, mark the 50deg spot on your floor, then run a string, tape, etc, from the corner across the 50deg mark you've made, straight out into the room and see where it ends up. If it is beyond the far side of your furthest listening position you are in good shape. If not, move up to 60deg coverage.

This is assuming that the speakers are flat against the walls. There's clearly some wiggle room with regard to separation while still covering the boundaries of your listening position.
vraxoin is offline
post #461 of 705 Old 05-22-2011, 04:34 PM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
The plasma is temporary, eventually an AT screen will be used (in a different room)
bodhisafa is offline
post #462 of 705 Old 05-22-2011, 04:51 PM
AVS Special Member

Ivan Beaver's Avatar

Join Date: Dec 2005
Posts: 1,639
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 44
Quote:
Originally Posted by bodhisafa View Post

Ivan,

So you are saying the SH 50 would not be appropriate for this room. Its only temporary (the room) eventually I will move to a new space.

I don't believe that I was saying that the SH50 would not be appropriate for the room.

Mainly that they should be a bit higher and the ceiling allows-but that would apply to any loudspeakers.

Since the Danley products have a sharp cutoff at the edges of the pattern (which can be good and bad at the same time), I generally advise going to a wider pattern to make sure everybody is in the pattern.

Especially if you are going to be moving and don't know what room you may end up with.

Danley Sound Labs

Physics-not fads
Ivan Beaver is offline
post #463 of 705 Old 05-22-2011, 04:59 PM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
I figured kutlow room being wider than mine by 4 feet and if he is using the Sh 50 for L R duties it could work for my narrow room

I understand the ceiling is an issue but if it wount affect the sound that much Iam willing to deal with it. The width coverage is what concerns me the most. It is usually just me in the room, so I dont need multiple seat coverage say 4 seats and 3 rows. I just have 2 rows and 2 seats, but again it just me or someone besides me.
bodhisafa is offline
post #464 of 705 Old 05-23-2011, 04:44 AM
AVS Special Member

Ivan Beaver's Avatar

Join Date: Dec 2005
Posts: 1,639
Mentioned: 2 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 44
Quote:
Originally Posted by bodhisafa View Post
I figured kutlow room being wider than mine by 4 feet and if he is using the Sh 50 for L R duties it could work for my narrow room

I understand the ceiling is an issue but if it wount affect the sound that much Iam willing to deal with it. The width coverage is what concerns me the most. It is usually just me in the room, so I dont need multiple seat coverage say 4 seats and 3 rows. I just have 2 rows and 2 seats, but again it just me or someone besides me.
It is not just the width that has to be considered. But also the listening distance from the loudspeakers. The further away you are-the narrower the coverage can be. If you are up close-then the coverage has to be wider.

The problem with your ceiling is that the loudspeakers should be higher. So you have to move them in to get them higher-which means they need to have a wider coverage pattern.

You can lay it all out on a scale piece of paper and use 50° (or 60°) angles to figure out what the coverage would be.

Danley Sound Labs

Physics-not fads
Ivan Beaver is offline
post #465 of 705 Old 05-23-2011, 07:43 AM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Using a protractor I mapped out the 50 degree angle and this is what I came up with.

Right Chanel:
Listening position 12 feet, SH 50 up against knee wall (wall is zero degrees), center of speaker about 44" high


bodhisafa is offline
post #466 of 705 Old 05-23-2011, 07:46 AM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Same situation as above except speaker is now 18.5" away from knee wall, putting center of speaker about 64" high


bodhisafa is offline
post #467 of 705 Old 05-23-2011, 07:51 AM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Left Chanel: upagainst knee wall (0 degrees), center of speaker about 44" high, listening position 12 feet away.


bodhisafa is offline
post #468 of 705 Old 05-23-2011, 07:53 AM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
Left chanel: 18.5" away from knee wall, speaker center about 64" high


bodhisafa is offline
post #469 of 705 Old 05-23-2011, 07:57 AM
Advanced Member

bodhisafa's Avatar

Join Date: Jul 2009
Location: 39046
Posts: 523
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 13
This is the best I can do at the moment, please critic my methods.

Moving the speaker in towards TV, gives a few extra inches to play with, not sure if thats enough?

What do you guys think?
bodhisafa is offline
post #470 of 705 Old 05-23-2011, 08:19 AM
AVS Special Member

Tom Bley's Avatar

Join Date: Jan 2001
Location: IL. USA
Posts: 2,226
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Liked: 20
Looks like you are good to go or if you wanted a little wider coverage patten you could always go with the SH-60.
Tom Bley is offline
post #471 of 705 Old 05-23-2011, 06:15 PM
Senior Member

misterkit's Avatar

Join Date: Dec 2006
Location: Rochester, NY
Posts: 480
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
So I'm still waiting for lions review.....
misterkit is offline
post #472 of 705 Old 05-23-2011, 07:46 PM
Advanced Member

vraxoin's Avatar

Join Date: Jan 2002
Location: SF Bay Area
Posts: 719
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 23
Quote:
Originally Posted by bodhisafa View Post

This is the best I can do at the moment, please critic my methods.

Moving the speaker in towards TV, gives a few extra inches to play with, not sure if thats enough?

What do you guys think?

I feel that's very solid front row coverage. The listener's head is multiple feet within the 50deg pattern boundaries. Obviously there are no horizontal coverage issues for the deeper rows, but vertical may be an issue for ideal coverage. Since this is a temporary situation it doesn't seem worth much worry as you can correct for it later on in the new room. Curious what Ivan's take is.
vraxoin is offline
post #473 of 705 Old 05-23-2011, 08:29 PM
AVS Special Member

kutlow's Avatar

Join Date: Sep 2006
Location: Wetumpka, Al
Posts: 2,363
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Liked: 14
Im on my way to West Virginia in the morning. I am going to try and stop by Danley to see the TH221 for a quick audition.

For those wondering about the SH50-SH69 -SH100 combo I can attest I am amazed by the fidelity. These speakers are just cruising along at 118DB. The SH100 are an incrediable surround speaker. My brother who has a pretty good ear for surrounds really is impressed. The 3 DTS 10'S really sound nice however I just want to see if I can hear a difference between those and a single TH221.
kutlow is offline
post #474 of 705 Old 05-23-2011, 09:37 PM
AVS Addicted Member

Join Date: Sep 2002
Location: Wetumpka, AL
Posts: 15,366
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 118 Post(s)
Liked: 191
Quote:
Originally Posted by kutlow View Post

...snip... I am going to try and stop by Danley to see the TH221 for a quick audition.

While you're there, go over and try to lift it. ....and then try to figure out how you're going to get it upstairs.

Samsung 64F8500, Panasonic 65VT50, Oppo 95, Tivo Roamio for OTA, Dish VIP722, Marantz AV8801 preamp, Rotel Amps, Atlantic Tech 8200 speakers, Seaton Submersive HP, Calman 5, Chromapure, Accupel DVG-5000, i1Display3pro, i1pro2, eecolor colorbox.
JimP is offline
post #475 of 705 Old 05-24-2011, 07:30 AM
Advanced Member

Ettepet's Avatar

Join Date: Jan 2003
Location: the Netherlands
Posts: 572
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
Quote:
Originally Posted by misterkit View Post

So I'm still waiting for lions review.....

Yes, I'm wandering too. I liked the depth of his comparison between his Genelecs and the (single) Catalyst he owns. Can't wait to hear what he thinks of the SH50's...

Sofar the SM60F's that arrived last week are doing quite well attached to my Onkyo TX-NR5008. The Onkyo is unable to combine "Speaker B" with my subwoofers, so I have to try some other configurations as well. Haven't tested them on my TAG av32dp yet. The coming 2 weeks I also plan to take them with me to a co-worker of mine who owns modified Quads and a high-end DAC.

One thing I like about the SM60's sofar is that they already sound good when they are positioned way on top of my current front speakers (4 feet 9 high). Standing up from a sitting position the sound changes little, which to me is quite impressive.
Ettepet is offline
post #476 of 705 Old 05-24-2011, 08:23 AM
AVS Special Member

Tom Bley's Avatar

Join Date: Jan 2001
Location: IL. USA
Posts: 2,226
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Liked: 20
Reading many peoples thoughts it sound like the Synergy horns can be placed higher up. I'm wondering if the SM-60 could be placed on or just above the DTS-10 which is 44". My listening posistion would be 11.5ft from speakers. I like the tri-pod mount that some are using.

I also am looking for Lions review.
Tom Bley is offline
post #477 of 705 Old 05-24-2011, 08:45 AM
Advanced Member

vraxoin's Avatar

Join Date: Jan 2002
Location: SF Bay Area
Posts: 719
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 23
Quote:
Originally Posted by Tom Bley View Post

Reading many peoples thoughts it sound like the Synergy horns can be placed higher up. I'm wondering if the SM-60 could be placed on or just above the DTS-10 which is 44". My listening posistion would be 11.5ft from speakers. I like the tri-pod mount that some are using.

I also am looking for Lions review.

I believe that we have a member who is already using exactly that configuration. If I can find the post with the pic I'll link it.
vraxoin is offline
post #478 of 705 Old 05-24-2011, 09:06 AM
AVS Special Member

Tom Bley's Avatar

Join Date: Jan 2001
Location: IL. USA
Posts: 2,226
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 8 Post(s)
Liked: 20
Quote:
Originally Posted by vraxoin View Post

I believe that we have a member who is already using exactly that configuration. If I can find the post with the pic I'll link it.

Page 8 shows them flown on a tri-pod stand. I think it was said that they are 47" from floor to bottom of speaker but, not sure on haw far back his listening position is or if he has slight angle downward.
Tom Bley is offline
post #479 of 705 Old 05-24-2011, 10:56 AM
Member

jheyau's Avatar

Join Date: Jan 2009
Posts: 79
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 14
Quote:
Originally Posted by vraxoin View Post

I believe that we have a member who is already using exactly that configuration. If I can find the post with the pic I'll link it.

Forin places his SM60Fs on top of his DTS 10s and he is thinking of getting another pair of SM60Fs AND a pair of DTS 10s for the rear channels!
jheyau is offline
post #480 of 705 Old 05-24-2011, 11:04 AM
Member

jheyau's Avatar

Join Date: Jan 2009
Posts: 79
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 14
Quote:
Originally Posted by Ettepet View Post

Yes, I'm wandering too. I liked the depth of his comparison between his Genelecs and the (single) Catalyst he owns. Can't wait to hear what he thinks of the SH50's...

Sofar the SM60F's that arrived last week are doing quite well attached to my Onkyo TX-NR5008. The Onkyo is unable to combine "Speaker B" with my subwoofers, so I have to try some other configurations as well. Haven't tested them on my TAG av32dp yet. The coming 2 weeks I also plan to take them with me to a co-worker of mine who owns modified Quads and a high-end DAC.

One thing I like about the SM60's sofar is that they already sound good when they are positioned way on top of my current front speakers (4 feet 9 high). Standing up from a sitting position the sound changes little, which to me is quite impressive.

I'm also waiting with great anticipation for Lion's review. I look forward to your comparison of the Danley to the Quads; be prepared to be surprised with Danley's vocal reproduction put up against the Quads!
jheyau is offline
Reply Speakers

User Tag List

Thread Tools
Show Printable Version Show Printable Version
Email this Page Email this Page


Forum Jump:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off
