post #11011 of 11036 Old Yesterday, 09:19 AM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
Yes I had aux input selected, master volume at -20 and no I didn't hear anything when I ran the mic.

jsil is online now
Sponsored Links
Advertisement

post #11012 of 11036 Old Yesterday, 10:15 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
What "output" do you have selected in the REW Preferences?

1=FL
2=FR
3=CC
4=LFE
Alan P is online now
post #11013 of 11036 Old Yesterday, 10:49 AM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
For output device I only get speaker as a choice.

jsil is online now
post #11014 of 11036 Old Yesterday, 10:52 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
You need to select ASIO under Drivers.
Alan P is online now
post #11015 of 11036 Old Yesterday, 10:54 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
Not to be a smarta**, but you have read Austin Jerry's awesome guide, right?
Alan P is online now
post #11016 of 11036 Old Yesterday, 10:56 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
Ooops, just notice you're using the "legacy" connections....not covered in the guide.

You'll want JAVA under Drivers, not ASIO.

Describe exactly how you have your computer hooked to your AVR.
Alan P is online now
post #11017 of 11036 Old Yesterday, 11:06 AM
AVS Special Member

AustinJerry's Avatar

Join Date: Jan 2003
Location: Austin, Texas
Posts: 7,019
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked: 669
Alan, have you read the guide? Non-HDMI connections are covered.
AustinJerry is offline
post #11018 of 11036 Old Yesterday, 11:07 AM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
No problem. I've gone though the guide about 3 times and still can't get sound through my speakers.

jsil is online now
post #11019 of 11036 Old Yesterday, 11:11 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
Quote:
Originally Posted by AustinJerry View Post
Alan, have you read the guide? Non-HDMI connections are covered.
Been a long time since I read the guide...sorry about the mis-information!
Alan P is online now
post #11020 of 11036 Old Yesterday, 11:13 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
You still didn't tell us how you have the laptop connected to your AVR...? Are you using the headphone jack on your laptop?
Alan P is online now
post #11021 of 11036 Old Yesterday, 11:30 AM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
I'm using 3.5 mm the headphone jack on your laptop. Looks like my computers jack is bad going to brought my friends laptop. Got it to work on my laptop had to play around with it and now I'm getting sound thanks.


Last edited by jsil; Yesterday at 11:35 AM.
jsil is online now
post #11022 of 11036 Old Yesterday, 11:38 AM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
Glad you got it sorted and looking forward to some measurements! Probably a dirty headphone jack.
Alan P is online now
post #11023 of 11036 Old Yesterday, 11:52 AM
AVS Special Member

AustinJerry's Avatar

Join Date: Jan 2003
Location: Austin, Texas
Posts: 7,019
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked: 669
Quote:
Originally Posted by jsil View Post
No problem. I've gone though the guide about 3 times and still can't get sound through my speakers.
OK, I assume that since you are not using HDMI, that either your laptop or your AVR doesn't support HDMI, correct? So let's walk through the non-HDMI configuration.

1. You should have a cable plugged into the headphone-out jack on the laptop. It should be a 3.5mm Stereo mini-plug on one end, and two RCA connectors on the other end (red for right, white for left). You should have a Y-cable connected to the red RCA plug on the cable from the laptop, and the other end of the Y-cable should be connected to the AUX IN left and right RCA connectors on the front of the AVR.

2. Your AVR output should be set to AUX IN (or AUX1, depending on the brand of your AVR). In the AVR Input Assign menu, the front panel AUX IN should be configured for ANALOG input (not HDMI).

3. On your laptop, before starting up REW, check the Windows audio settings for the laptop. Level should be 100%, Enhancements should be disabled, and Advance setting should be 48000Hz.



4. After loading REW, check the Preferences tab. Driver should be Java, Sample rate 48kHz, Output device Speaker, Input channel right, and Control input mixer/volume unchecked.




With these settings, you should be able to open the Generator tool, select something like Sine wave, and play a tone that comes out your main speakers. If still no sound, my first thing I would do is swap out the cables between the laptop and the AVR. I just set this up myself, and had a bad cable, which resulted in no sound, obviously.

BTW, you posted some measurements back in July, so REW must have been working then. What changed between July and now?
AustinJerry is offline
post #11024 of 11036 Old Yesterday, 12:53 PM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
I was using someone else's computer and mic to test my KEF speakers. Now that I got my own stuff, would like to learn how to use REW. I got it to work but my wife's at home and making a lot of noise.

jsil is online now
post #11025 of 11036 Old Yesterday, 01:06 PM
AVS Special Member

jkasanic's Avatar

Join Date: Dec 2006
Posts: 1,141
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked: 57
Quote:
Originally Posted by AustinJerry View Post
OK, I assume that since you are not using HDMI, that either your laptop or your AVR doesn't support HDMI, correct? So let's walk through the non-HDMI configuration.

1. You should have a cable plugged into the headphone-out jack on the laptop. It should be a 3.5mm Stereo mini-plug on one end, and two RCA connectors on the other end (red for right, white for left). You should have a Y-cable connected to the red RCA plug on the cable from the laptop, and the other end of the Y-cable should be connected to the AUX IN left and right RCA connectors on the front of the AVR.
Jerry, I thought you determined a while ago that the mono signal was output to both L and R RCA plugs so the Y cable wasn't necessary? This is how I've been doing my latest set of measurements and I haven't noticed any difference. Did something change?
jkasanic is offline
post #11026 of 11036 Old Yesterday, 01:07 PM
AVS Special Member

AustinJerry's Avatar

Join Date: Jan 2003
Location: Austin, Texas
Posts: 7,019
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked: 669
Quote:
Originally Posted by jsil View Post
I was using someone else's computer and mic to test my KEF speakers. Now that I got my own stuff, would like to learn how to use REW. I got it to work but my wife's at home and making a lot of noise.
Whoa! After the help we have given you, don't you think it would be appropriate to share with us how you got it working, and what you were doing wrong?
Alan P likes this.
AustinJerry is offline
post #11027 of 11036 Old Yesterday, 01:10 PM
AVS Special Member

AustinJerry's Avatar

Join Date: Jan 2003
Location: Austin, Texas
Posts: 7,019
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked: 669
Quote:
Originally Posted by jkasanic View Post
Jerry, I thought you determined a while ago that the mono signal was output to both L and R RCA plugs so the Y cable wasn't necessary? This is how I've been doing my latest set of measurements and I haven't noticed any difference. Did something change?
TBH, I don't remember. I don't use the Java hookup enough to know one way or the other. If it works either way, that shouldn't prevent the OP from getting his setup working properly.
AustinJerry is offline
post #11028 of 11036 Old Yesterday, 01:14 PM
AVS Special Member

jkasanic's Avatar

Join Date: Dec 2006
Posts: 1,141
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 22 Post(s)
Liked: 57
Quote:
Originally Posted by AustinJerry View Post
TBH, I don't remember. I don't use the Java hookup enough to know one way or the other. If it works either way, that shouldn't prevent the OP from getting his setup working properly.
No worries...I just re-read v3.7 of the Guide and you removed the reference to the Y cable for legacy connections (presumably as a result of discovering the mono signal was output to both jacks).

EDIT: Looks like rev3.5 implemented the change as a result of this feedback from batpig

Last edited by jkasanic; Yesterday at 01:23 PM.
jkasanic is offline
post #11029 of 11036 Old Yesterday, 01:20 PM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
Look at post 11021. I just play around with the headphone jack on my computer and it worked. Looks like I could have a bad input on my computer.

jsil is online now
post #11030 of 11036 Old Yesterday, 01:27 PM
AVS Special Member

AustinJerry's Avatar

Join Date: Jan 2003
Location: Austin, Texas
Posts: 7,019
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked: 669
Quote:
Originally Posted by jsil View Post
Look at post 11021. I just play around with the headphone jack on my computer and it worked. Looks like I could have a bad input on my computer.
Sorry, it looks like I missed a couple of posts while I was crafting my response. Moving forward now...
AustinJerry is offline
post #11031 of 11036 Old Yesterday, 01:40 PM
AVS Special Member

jsil's Avatar

Join Date: Oct 2002
Location: San Jose, CA
Posts: 1,611
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 10 Post(s)
Liked: 16
No problem will still need your guy's help later on when I get going with REW.

jsil is online now
post #11032 of 11036 Old Yesterday, 03:06 PM
JW6
Member

JW6's Avatar

Join Date: Jan 2010
Posts: 50
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Liked: 10
Just orderered the Calibrated Dayton UMM-6. Vintage REW entailed me using my music stand with duck taped 1.5' tripod on end Worked pretty well actually. You guys see any real detriment to measuring? I have solid basment floor with tile. Seems to me they're all fairly simlilar to my duck tape solution
JW6 is offline
post #11033 of 11036 Old Yesterday, 03:11 PM
AVS Special Member

Alan P's Avatar

Join Date: Jan 2003
Location: South Dakota
Posts: 2,037
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 289 Post(s)
Liked: 188
Should be fine JW as long as you can orient the mic correctly (90 degrees) at ear level in the MLP.
Alan P is online now
post #11034 of 11036 Old Yesterday, 03:21 PM
AVS Special Member

AustinJerry's Avatar

Join Date: Jan 2003
Location: Austin, Texas
Posts: 7,019
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 376 Post(s)
Liked: 669
Quote:
Originally Posted by JW6 View Post
Just orderered the Calibrated Dayton UMM-6. Vintage REW entailed me using my music stand with duck taped 1.5' tripod on end Worked pretty well actually. You guys see any real detriment to measuring? I have solid basment floor with tile. Seems to me they're all fairly simlilar to my duck tape solution
Also keep in mind that a proper boom mic stand can be purchased from places like Musicians Friend or Guitar Center for less than $30. Being able to easily place the mic makes repeated REW measurements much easier. Try the music stand, but know there are inexpensive, but better, options.
AustinJerry is offline
post #11035 of 11036 Old Yesterday, 04:26 PM
JW6
Member

JW6's Avatar

Join Date: Jan 2010
Posts: 50
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Liked: 10
Quote:
Originally Posted by AustinJerry View Post
Also keep in mind that a proper boom mic stand can be purchased from places like Musicians Friend or Guitar Center for less than $30. Being able to easily place the mic makes repeated REW measurements much easier. Try the music stand, but know there are inexpensive, but better, options.

Haha. Very true. Thanks so much guys. CANNOT wait to get reorientated with REW with a proper mic as opposed to the RS meter of old. Also have the ole DTS 10...always room to improve on taming that beast Interesting looking at my old graphs. Modal ringing showing the inherent "54hz ringing" with the decay yet the freq. chart was relatively tame. ...finally going to be able to get this right This time I'll pay the proper respect to the waterfalls. TY!!
JW6 is offline
post #11036 of 11036 Old Yesterday, 04:29 PM
JW6
Member

JW6's Avatar

Join Date: Jan 2010
Posts: 50
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 3 Post(s)
Liked: 10
SOOO tempted to pull out all my treatments (including the "super chunks that were considered benchmark) and properly do this right this time around. Will probably just be defeated after looking at the DTS 10 and imagining moving this thing all over again
JW6 is offline
