Made a bit more progress as we finished the trim at the riser steps, stained and hung the doors and finished the crown and rope lighting.

I took a shot at giving the base trim a more finished look at the riser. I started with a piece of 1 1/4" x 6"inner corner accent trim and kept cutting away until I had something that fit the scale of trim. A "real" finish carpenter may grimace at my amateur attempt but I like it

Here's the before:


Here's the after:


My wife stained and finished the doors and I installed them. The entrance door sticks a bit - going to need some sanding. The wierd thing is when I cut the bottom and top down, I also planed the side and it fit perfectly.

Anyway, here's the entrance door


Here's the door to the eq rack and utility room


Made a mistake when finishing the moulding. Picked up couple of tubes of white caulk to seal the inside of the crown to prevent light leaks. The next day while prepping to install the rope light, I noticed I could see right through the cured caulk - it was as clear as glass. I'd used clear drying caulk to block light. We took a brush and painted the caulk so it wasn't a big deal.

Drill a hole in my projector box for the rope light outlet


The light laid in the crown easily enough but it didn't look the way I wanted on the ceiling:


I figured I'd have to use the clips and screws that came with the light to straighten everything. Since the crown was already up I started to attach the clips to the drywall. I realized that gently pushing the rope to the base of the crown channel held it there for the most part. Here and there, I used the clips to hold down the lights but it went pretty smooth and I got the look I wanted.








In the last pic you still see some unevenness in the lighting to the right of the projector box. I had 2 1/2 feet too much of rope and just doubled it up for now. Anybody know where I can get 4 feet of rope light?

My To Do list now looks loosely like this:
- (COMPLETE) finish the trim at the riser steps
- (COMPLETE) get the doors stained and hung
- (COMPLETE) install the crown moulding and rope lighting
- finish the LV wiring install
- build minimalist screenwall with rear access and AT screen
- order the pieces of gear I do not yet possess, yet crave.
- on wall acoustic treatments

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
Sponsored Links
Advertisement

post #212 of 419 Old 08-05-2009, 07:58 AM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Small update:
- We finished our minimalist screen wall framing
- I think I have a plan for hinging my screen
- I'm expecting chairs any day now (possibly today)

After lots of input in my screen wall design thread, I decided to build this plan:


I picked up some 2x4's and screws (why do I continue to buy screws - I probably have enough to build an entire house) and assembled the pieces. Here they are in the paint shop just before a coat of Model T black by my wife and daughter.


After a little time with a level and some string, I got this. Do you think there is enough room for me to slip by - I may have to turn sideways and think skinny.


I decided to forgo the middle support pieces as the framing is significantly sturdier than I thought it would be. I performed a number of tug and lean tests to determine if the framing could support a 33 lb screen. I didn't do a Ted White hanging by hat channel test, but I'd guess the collective framing will easily support ~100+ lbs or so.

So, now, I've narrowed my hinged screen design to two choices. The first uses hinged wooden framing to support the screen with both supported by lift supports when needed. This will work (I think) but the framing support will add weight and push the screen an inch or so away from the false wall.


After reviewing a DIY hinged screen link provided by dc_pilgrim, I decided I could hinge the screen directly to the false wall to save weight and minimize screen protrusion. I'd planned to build a screen after seeing guam's DIY work, but I've recently become smitten with Seymour AV's new fixed frame screen. The challenge here is figuring out how to attach the hinges and lift supports to the aluminum frame.


I think I'm fairly close to a successful plan either way. What do you guys think?

Getting closer..

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #213 of 419 Old 08-05-2009, 12:49 PM
AVS Forum Special Member

mn_hokie's Avatar

Join Date: Jul 2004
Location: Minneapolis, MN
Posts: 2,466
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 28
So far so good. Looking forward to seeing it come to completion.
mn_hokie is offline
Sponsored Links
Advertisement

post #214 of 419 Old 08-05-2009, 01:36 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks Jason,

I'm excited to see construction completed as well. It seems like my image of the room is really coming together nicely as I imagined it at the start, but I'm just not quite there yet with the screen wall. Feels like I'm getting really close...

This will help: My wife just called and said the chairs have been delivered. Can't wait to get home and check them out. Hopefully, I'll be able to post a pic or two.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #215 of 419 Old 08-05-2009, 10:01 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
The chairs are in! All set up and ready... I wish the room was already complete. I've got work to do.

The flash makes the chairs look slightly lighter than they really are. Despite being a bit larger than our original choice, they fit the room well. The power recline is smooth and the seats are comfy. I haven't had a chance to test out the BKs yet.





Gotta get to work on that screen.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #216 of 419 Old 08-05-2009, 10:20 PM
AVS Forum Special Member

mn_hokie's Avatar

Join Date: Jul 2004
Location: Minneapolis, MN
Posts: 2,466
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 28
Very nice. I'm ALWAYS envious of you guys that can fit a row of 4 in your room
mn_hokie is offline
post #217 of 419 Old 08-06-2009, 07:49 AM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thank Jason,

The 13175 row of four is 4" wider at 116" than the Ovations I'd planned for. When I switched my order, I was concerned enough about the width difference that I strongly considered 3 seats for the front row, even taped the dimensions on the floor. But we decided to take a chance on two rows of four reasoning that if a front row of 3 looked better, we could sell the extra seat.

Here's a pic of the tape job. The outer blue is the current 13175 config; the inner blue is the 13175 in 3 seat config; and the white is the Ovations in 4 seat.


Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #218 of 419 Old 08-06-2009, 12:47 PM
AVS Forum Special Member

mn_hokie's Avatar

Join Date: Jul 2004
Location: Minneapolis, MN
Posts: 2,466
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 28
I'm quite familiar with the "tape off the seat" thing. did that several times myself when trying to find the right seats.. lol. Mine are actually pretty snug in the back row.

4 is definately the way to go if you have the room for it. The only thing I don't like about my 3 and 3 setup is that it's odd for couples when we have 6 people down there. The end result is that my wife and I usually end up sitting in seperate rows so that the visitors can be together.
mn_hokie is offline
post #219 of 419 Old 08-17-2009, 12:37 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
A lot has happened since my last update. We made our DIY scope screen using Seymour AV's AT fabric and the staple method. Final viewable width is 111.5. I took lots of pictures to document the process.

I began with 1x3 poplar mitered at the corners.


Added a bevel to the inside edge


Laid the pieces out in the garage for a test fit


Then wrapped and stapled them in velveteen from Hancock fabrics


My stapler worked just okay. The hammer was needed to finish up


I used metal brackets to secure the corners






Here is the finished frame


Building the frame was a fun family project that turned out well.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #220 of 419 Old 08-17-2009, 12:44 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
While waiting for my screen material, my low voltage wiring bits for the riser I/O panels arrived so I finished that install up. Didn't get a pic of the subwoofer outlets or the CAT6, VGA, USB panel. I plan to paint the outlet covers dark brown, but with the 1st row chairs in front of them, I may leave them like this:

Maybe not - those covers look really bright in the pic

Chris at Seymour AV was very helpful and suggested that I beef up the screen frame as much as possible (since I'd planned to use lift supports - more on the past tense in a bit). Back to the hardware store and I added these:

Subsequently, I replaced the 4 outer brackets with 6 brackets to add more support

Confident the frame would hold, we added the screen material. After wrapping the frame with velvet went so smoothly, I thought the screen material install would be easy as well. It took considerably more patience to install the material without any ripples. We redid the stapling four times to get it right and got this:


So, we added two hinges to the minimalist screen wall and new screen




And got this:

Level, centered, light weight with free movement. I was pumped.

With the screen in place, I anxiously installed my lift supports bits. I don't have any pictures of the next series of events but the lift support plan did not work. As explained here in post #61 https://www.avsforum.com/avs-vb/showt...1139467&page=2 I made a number of construction mistakes that I feel compromised the lift idea. But, it seems the hinge selection and the DIY 1x3 frame were weak points as well as the span bowed and twisted when I connected the lift supports. I still think a more robust frame with a piano hinge would be successful. I may revisit the lift support idea at some point as I planned for my screen wall to work with or without them.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #221 of 419 Old 08-17-2009, 12:48 PM
AVS Forum Club Gold

JeffC's Avatar

Join Date: Mar 2003
Location: Hawkeye State
Posts: 1,554
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
Far out! Looking good!

If I had it to do all over again, I'd still hit that shot.
Ht Build

Poker table and bar
JeffC is offline
post #222 of 419 Old 08-17-2009, 12:51 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
With my screen undamaged I decided to work on my false wall panels. Picked up some pine 1x2s and 1x4s. I couldn't find enough straight 1x2s so my son and I ripped the 1x4s.

I made the side framing first.


Then, I cut and laid out the top and bottom panels in the garage.


Here is a panel being made.








Test fitting in the HT


Everything sanded and ready for paint


My wood shop is now a paint shop. All pieces ready for speaker fabric from JoAnn's. The clerk's name was Ann. I thought of a few jokes but kept them to myself.


I do not have any pics of the fabric install as my wife finished them all while I was on grill dutyYes. A few dabs of Velcro later and we had this:






The screen wall just disappears. If I look hard enough in full light, I can see the seams. But, in movie lighting, the screen just floats. Yes!

My To Do list now looks loosely like this:
- (COMPLETE) finish the trim at the riser steps
- (COMPLETE) get the doors stained and hung
- (COMPLETE) install the crown moulding and rope lighting
- (COMPLETE) finish the LV wiring install
- (COMPLETE) build minimalist screenwall with rear access and AT screen
- order the pieces of gear I do not yet possess, yet crave.
- screen wall and in room acoustic treatments

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #223 of 419 Old 08-17-2009, 12:52 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks Jeff.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #224 of 419 Old 08-17-2009, 01:02 PM
AVS Forum Special Member

In2Photos's Avatar

Join Date: Apr 2008
Location: Monroe, NC
Posts: 1,974
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Liked: 13
Looking good!

Mike
In2Photos is offline
post #225 of 419 Old 08-17-2009, 01:05 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks Mike. Think its about time I started using a tripod for the pics, heh?

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #226 of 419 Old 08-17-2009, 01:13 PM
AVS Forum Special Member

In2Photos's Avatar

Join Date: Apr 2008
Location: Monroe, NC
Posts: 1,974
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 1 Post(s)
Liked: 13
Quote:
Originally Posted by kjlewie View Post

Thanks Mike. Think its about time I started using a tripod for the pics, heh?

LOL, they are not too bad actually. When it comes time to get those screen shots and lighting shots make sure you use it though.

Mike
In2Photos is offline
post #227 of 419 Old 08-17-2009, 05:29 PM
Advanced Member

KNKKNK's Avatar

Join Date: Feb 2009
Location: AZ
Posts: 887
Mentioned: 3 Post(s)
Tagged: 0 Thread(s)
Quoted: 39 Post(s)
Liked: 104
Nice Work!! Looking great KJ!!

Brad

My Basement HT Construction ~ Faster than the speed of Dark

"I've cut that piece 3 times and its still too short..."
KNKKNK is offline
post #228 of 419 Old 08-17-2009, 10:01 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks Brad.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #229 of 419 Old 08-18-2009, 08:08 AM
Senior Member

Todd Lee's Avatar

Join Date: May 2005
Location: Kaysville, UT
Posts: 348
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 10
Very sharp!! The screen really 'pops' against the velvet.
Todd Lee is offline
post #230 of 419 Old 08-18-2009, 08:22 AM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks Todd,

Now, I need to get some equipment ordered and installed to test it out.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #231 of 419 Old 08-18-2009, 06:52 PM

dogone's Avatar

Join Date: Apr 2008
Posts: 2,156
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 11
Great job!...It will be such a rewarding feeling sitting in there when it's finished...I'm sure you already sit in there in the wee hours of the morning and just stare with amazement at your accomplishment... Nothin like it!...
dogone is offline
post #232 of 419 Old 08-18-2009, 08:02 PM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Quote:
Originally Posted by dogone View Post

Great job!...It will be such a rewarding feeling sitting in there when it's finished...I'm sure you already sit in there in the wee hours of the morning and just stare with amazement at your accomplishment... Nothin like it!...

My morning coffee consumption has increased considerably

Thanks

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #233 of 419 Old 08-18-2009, 08:32 PM
AVS Forum Special Member

mn_hokie's Avatar

Join Date: Jul 2004
Location: Minneapolis, MN
Posts: 2,466
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 6 Post(s)
Liked: 28
Ha!! Too funny. I can remember sitting and staring at the taped off image on my wall for hours. I know my wife thought (and still does think) I was crazy.
mn_hokie is offline
post #234 of 419 Old 08-22-2009, 05:26 PM
Member

JohnnyFriday's Avatar

Join Date: May 2009
Location: Denison, IA
Posts: 122
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Liked: 10
I just wanted to impart how impressed and envious I am of your theatre room. Fantastic Job man, really.
JohnnyFriday is offline
post #235 of 419 Old 08-24-2009, 08:04 AM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks Johnny.

I really appreciate the kind comments.

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #236 of 419 Old 08-24-2009, 08:23 AM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Since I've put my screen lift project on hold and after not being satisfied with my first attempt at a DIY rack, I decided to spend some time on my screen wall acoustic treatments. Originally, like many others, I'd planned to use OC703 and fabric as it is the best combination of affordability and acoustic performance that I could find. But, mindful of the need for ongoing access with the frequently running sump pump and the electrical panel, I decided to use something that wouldn't likely stir up a bunch of nasties when I started rustling around back there. After reading about it in Jamis' build, I thought that acoustic cotton would fit my needs as it practically matches OC703 for acoustic performance and needs no fabric covering. But, it is quite a bit more expensive than I'd hoped.

I chose acoustic foam as it had the right compromise of acoustic performance, aesthetics, and price for me. Though it is not the same material, I got the idea from Sandman's thread. Each wedge panel is 12x12x3 (12x12x1 on the ceiling) and the bass traps are stacked 12x12x24 pieces. I used 3M spray adhesive on all but the lower left bass trap. It is friction fitted above the corner of the sump pump access. Enough words, here are pics for reference.

A shot from the lower left (facing the screen) along the rear wall to the right side bass trap


The right side with the pillar treated


The left side with the breaker panel, sump equipment and removable bass trap


The treated ceiling


The ceiling bass trap - got the tip from guam




Here is a pic of the false panels going back on. You can see the opening on the lower left side that I use for access when the screen doesn't need to be lifted.


With everything back in place, the finished screen wall looks like this



I installed some accent lighting for zone 5 on the GE and got this


No real acoustic impressions yet as I'm waiting for gear to start arriving, but I think it looks pretty cool. I'll add a little velvet to hide the panel gaps where the screen hinges. Aside from a few other finishing touches, the construction of the room is basically complete. I still need a rack and in-room acoustic treatments but I may live with the room for a while before deciding what to do. I also need to decide on a remote control system and a projector.

My To Do list now looks loosely like this:
- (COMPLETE) finish the trim at the riser steps
- (COMPLETE) get the doors stained and hung
- (COMPLETE) install the crown moulding and rope lighting
- (COMPLETE) finish the LV wiring install
- (COMPLETE) build minimalist screenwall with rear access and AT screen
- (EFFORTING) order and install the pieces of gear I do not yet possess, yet crave.
- (COMPLETE) screen wall and in room acoustic treatments

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #237 of 419 Old 08-24-2009, 08:38 AM
AVS Forum Club Gold

dc_pilgrim's Avatar

Join Date: Oct 2004
Location: Philly
Posts: 4,606
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 7 Post(s)
Liked: 20
Wow - its been ages since I looked in your build thread. Looks amazing.
dc_pilgrim is offline
post #238 of 419 Old 08-24-2009, 08:41 AM
AVS Forum Special Member

oman321's Avatar

Join Date: Sep 2005
Location: MASS
Posts: 4,939
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 127 Post(s)
Liked: 117
Very nice KJ. I thought that acoustic foam was really expensive though. Where did you them from?
oman321 is offline
post #239 of 419 Old 08-24-2009, 09:22 AM - Thread Starter
AVS Forum Special Member

kjlewie's Avatar

Join Date: May 2008
Location: Marion, Iowa
Posts: 1,195
Mentioned: 19 Post(s)
Tagged: 1 Thread(s)
Quoted: 95 Post(s)
Liked: 120
Thanks dc - seems like it has been ages since I started the build.

Thanks oman. Yes, compared to OC703 and fabric, the acoustic foam is more expensive. I don't recall what I priced the OC703 and fabric at, but I treated everything in foam (including 2 cans of spray adhesive) for 1/3 of the quote I received for acoustic cotton (also included spray adhesive).

I got it here: http://www.thefoamfactory.com/acoust...usticfoam.html

Audio: Marantz AV7702mkII / Marantz MM8077 / Emotiva UPA-7 for 7.2.4 Atmos/DTS:X
Video: Sony VPL-VW600ES & SI Black Diamond 133" 2.35:1 CIH for 4K UHD
Sources: Oppo BDP-103D, Mede8er 600d with Synology ds716 NAS (28tb), PS4, DirecTV
7. Paradigm Studio 20 v5 (L, R, FW), CC-590 v5 (C), Sonance VP63 (SS); 2. DIYSG DA HO 18" (4); PSA S3000i (3); 4! Infinity Entra One (FH), Sonance VP65R (TR)
Lewis Family Cinema 2.0, Lewis Family Cinema 1.0
kjlewie is offline
post #240 of 419 Old 08-24-2009, 10:22 AM
AVS Forum Special Member

oman321's Avatar

Join Date: Sep 2005
Location: MASS
Posts: 4,939
Mentioned: 9 Post(s)
Tagged: 0 Thread(s)
Quoted: 127 Post(s)
Liked: 117
KJ, the pricing on those look really reasonable... I could've sworn the pricing on Sandman's were pretty far out there. Definately gonna consider these as the option for my screenwall.

3" on walls 1" on ceiling and 24" for bass traps. Awesome thanks for the link.
oman321 is offline
Sponsored Links
Advertisement

Reply Dedicated Theater Design & Construction

Thread Tools
Show Printable Version Show Printable Version
Email this Page Email this Page


Forum Jump:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off
