Discussion Starter · #1 · (Edited)
He's Baaaaaack,10 years later.


"The Thunder Deck", 1993 in my Fraternity House, (brothers gave it that name:D) I simply put my 2 car subs under a deck we built and turned the lights out for VHS movies in stereo on my 32" Sony Trinitron. Then Thunder Deck II in my old house, in 2006 (AVS Thread in my Sig).
Fast Forward 10 years to today....new house, Thunder Deck III. House is 4000 sq ft, Toll Brothers home, we're finishing the basement and gotta have a Theater. This one is going to be bigger in every way, about 16' wide, 24' long, with a pool table are directly behind separated by a halfwall with square columns and soffit above.....and dual steps on either side to enter the Theater Area. Here's the plans and unfinished pics.


The concept behind the "Thunder Deck" is for the seating area to be a raised/floating deck (2x12s resting on the floor plates at the walls, about 2" above the concrete floor). My 15" subwoofer will be in the floor, under where the coffee table will be, firing up through the carpet with a 4" port. (all designed for the exact enclosure specs). My last Theater was 14' square, with 2x10s, and a 12" subwoofer.


Keep the comments and suggestions coming.









·
Registered
Joined
·
1,788 Posts
Discussion Starter · #2 · (Edited)
We got some framing done this week, you can see the Deck, the sub enclosure, the steps, columns and soffit.

View of Screen Wall, Center will be in wall under the screen, Left and Right fronts will be in the bump outs. I had to have them because the Builder put the toilet pit to the left of the screen wall, so we had to box that in


·
Registered
Joined
·
1,788 Posts
Discussion Starter · #3 · (Edited)
Here's the sub enclosure in the Deck. It worked out perfect, the Kicker 15" that needs 3 cubic feet. The math for the Golden Ratio (.66 x 1.0 x 1.66) was 11.5h x 17d x 28w....11.5 is almost exactly the depth of a 2x12.....and all we had to do is shift the 2x12s a little to give us 17" inside between the 2.
